Based in Delhi, India, Kunj Sheets and Plates is a top producer and supplier of A286 Sheets and Plates, providing high-performance alloys that are resistant to heat and corrosion for demanding industries. Kunj Sheets and Plates is well-known for providing premium materials that satisfy global standards. Their A286 products have outstanding fabricability, oxidation resistance, and mechanical strength. Our A286 sheets and plates are offered in a range of sizes and finishes to meet the needs of industries like power generation, chemical processing, automotive, and aerospace. We are dedicated to offering top-notch products, prompt delivery, and outstanding customer support throughout India and beyond.
24–27% nickel, 13.5–16% chromium, 1%–2% molybdenum, 1.9–2.35% titanium, and trace amounts of vanadium and aluminium make up the iron-based superalloy known as A286. It provides good corrosion resistance, oxidation resistance up to 700°C (1290°F), and exceptional high-temperature strength. A286 has an elongation of 20–25%, a yield strength of 585 MPa, and a tensile strength of roughly 1000 MPa. It is appropriate for high-stress situations due to its good fabricability and creep resistance. It is also a material that works well in a variety of industries because it retains its toughness and ductility even under cryogenic conditions.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS |
| A286 | 1.4980 | S66286 |
Applications needing high strength and resistance to corrosion at high temperatures frequently use A286 Sheets and Plates. They are utilised in the aerospace sector for afterburner, jet engine, and turbine components. A286 is used in exhaust systems and manifolds in the automotive industry. It is utilised for heat exchangers, fasteners, and springs exposed to high temperatures and corrosive conditions in chemical processing and power plants. It is also perfect for parts like bolts, nuts, and industrial gas turbines where temperature resistance and mechanical performance are crucial due to its exceptional creep strength.
