Based in Delhi, India, Kunj Sheets and Plates is a top producer and supplier of Alloy 20 Steel Angles, providing high-quality, corrosion-resistant goods for a range of industrial uses. We are renowned for providing high-performance nickel-iron-chromium alloys, and we provide Alloy 20 angles that satisfy international quality standards, guaranteeing exceptional resistance to corrosion caused by sulfuric acid, pitting, and chloride. Our Alloy 20 steel angles, which come in a range of sizes and dimensions, are used in the food processing, chemical processing, pharmaceutical, marine, and power generation industries. Kunj guarantees total client satisfaction by emphasising accuracy, robustness, and prompt delivery.
Alloy 20 is a nickel-iron-chromium alloy that is stabilised with niobium and contains roughly 32–38% nickel, 19–21% chromium, 2–3% molybdenum, and 3–4% copper. With a tensile strength of about 620 MPa, a yield strength of 300 MPa, and an elongation of 30–40%, alloy 20 steel angles provide exceptional corrosion resistance, especially in sulphuric acid environments. These angles are appropriate for structural applications exposed to extremely corrosive or acidic environments because they retain good ductility, toughness, and weldability over a broad temperature range.
Specifications : ASTM B473, B464, B468 / ASME SB473, SB464, SB468
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | EN | AFNOR |
| Alloy 20 | 2.4660 | N08020 | NiCr20CuMo | Z2NCUD31-20AZ |
| Grade | C | Mn | Si | S | P | Fe | Ni | Cr | Mo | Cu |
| Alloy 20 | 0.07 max | 2.00 max | 1.00 max | 0.035 max | 0.045 max | 29.85 min | 32.00 – 38.00 | 19.00 – 21.00 | 2.00 – 3.00 | 3.00 – 4.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Alloy 20 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Yes, we offer custom sizes for Alloy 20 Steel Angle to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@kunjsheetsandplates.co.in.
Industries needing robust, corrosion-resistant support structures frequently use alloy 20 steel angles. They act as bracing, supports, and frames for tanks and piping systems exposed to acidic chemicals in chemical processing facilities. Alloy 20 angles are used in the structural assemblies and frames of sanitary equipment used in the food processing and pharmaceutical industries. They are used in ship fittings, offshore platforms, and seawater components in maritime environments. Alloy 20 angles are also used in petrochemical and power generation facilities for corrosion-resistant structural components that can survive demanding and harsh operating environments.
