Kunj Sheets and Plates is a renowned manufacturer and supplier of premium quality Aluminium Channels in Delhi, India. With years of experience and a firm commitment to precision engineering, Kunj provides superior-quality aluminium products for varied industrial and commercial applications. Our Aluminium Channels are renowned for their strength, corrosion resistance, and light weight, and are designed to conform to national and international quality parameters. For structural systems, building applications, or bespoke fabrication requirements, Kunj delivers reliable and affordable aluminium solutions with quick delivery and superior customer service.
Aluminium Channels are usually manufactured from alloy grades like 6061, 6063, or 6082, which are renowned for their outstanding strength-to-weight ratio and durability against corrosion. These alloys consist mainly of aluminium (90–98%) accompanied by varying percentages of magnesium, silicon, and trace elements. Mechanical properties are comprised of a tensile strength between 150 and 290 MPa and good machinability. Aluminium Channels have high electrical and thermal conductivity, fair weldability, and excellent resistance to environmental degradation, suitable for load-bearing and precision applications across various industrial fields.
| Specifications | : | ASTM B308 / ASME B308 |
| Dimensions | : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Aluminium 6061 Angle | : | 5mm to 9mm |
| Aluminium 6061 Channel | : | 40mm*20mm~300mm*300mm |
| Aluminium 6061 Beam | : | 3″ thru 12.31″ |
| Aluminium 6061 Chain | : | 1/8 inch – 1/2 inch Diameter |
| Thickness | : | 3.0mm – 120mm |
| Length | : | 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes |
| Type | : | Angle, C Channel, U Channel, H Beam, I Beam, T Beam, W Beam, Chain |
| Grade | Si | Fe | Cu | Zn | Mn | Mg | Ti | Cr | Al | Others(Total) |
| Aluminium | 0.40 – 0.80 | 0.70 max | 0.15-0.40 | 0.25 max | 0.15 | 0.8-1.2 | 0.15 max | 0.04-0.35 | Balance | 0.15 max |
| Temper | Tensile | Hardness | ||||
| Ultimate | Yield | Elongation | Brinell | |||
| KSI | MPA | KSI | MPA | % | ||
| T6, T651 | 45 | 310 | 21 | 145 | 25 | 65 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Aluminium channels offer several key benefits, including excellent corrosion resistance, making them ideal for outdoor and marine applications. Their lightweight nature reduces transportation and handling costs, while still providing impressive strength and durability. Aluminium channels are highly versatile, easily fabricated, and can be anodized for enhanced appearance and protection. They also have excellent thermal and electrical conductivity, making them suitable for various engineering applications. Additionally, aluminium’s eco-friendly properties, including its recyclability, make it a sustainable choice for industries looking to reduce their environmental impact.
Yes, we offer custom sizes for Aluminium Channel to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Aluminium Channels find extensive application across various industries owing to their versatility, strength, and light weight. They are employed in construction for framing, support members, and curtain wall systems. The transport industry employs them in truck bodies, rail cars, and sea use because they are corrosion-resistant. In the electrical sector, they are used as cable trays and casing. Aluminium Channels are also utilized in manufacturing equipment, solar panel frames, and furniture. Their recyclability and non-toxicity make them a sustainable option for use in contemporary infrastructure, providing both practical and aesthetic returns across a range of structural and architectural applications.
