Providing high-quality materials designed for demanding industrial settings, Kunj Sheets and Plates is a well-known manufacturer and supplier of Copper Nickel 70/30 Sheets and Plates in Chennai, India. Our Copper Nickel 70/30 Sheets and Plates are perfect for chemical and marine applications because of their exceptional strength, superior corrosion resistance, and thermal conductivity. Our products are guaranteed to meet international standards thanks to our state-of-the-art manufacturing facilities and rigorous quality checks. Kunj Sheets and Plates is dedicated to providing high-performance, long-lasting, and reasonably priced metal solutions with timely delivery and attentive service, and it has earned the trust of customers in the shipbuilding, power generation, and offshore industries.
Copper Nickel 70/30 Sheets and Plates are made up of 70% copper and 30% nickel, with trace amounts of iron and manganese added for strength and corrosion resistance. These plates offer superior stress corrosion and erosion resistance, as well as remarkable resistance to biofouling and seawater. They have an elongation rate of about 30%, a yield strength of about 130–200 MPa, and a tensile strength of 320–500 MPa. The alloy is appropriate for structural and thermal transfer applications in challenging conditions because it exhibits exceptional formability, weldability, and toughness while maintaining mechanical stability at high temperatures.
| Specifications | : | ASTM / ASME SB 122 |
| Size | : | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | : | 0.1mm to 12 mm Thk |
| Form | : | Plain Sheet, Shim Sheet |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cupro Nickel 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 70/30 | 2.0882 | C71500 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Copper Nickel 70/30 Sheets and Plates offer excellent corrosion resistance, particularly in marine and industrial environments, making them ideal for seawater applications. Their high strength and excellent resistance to biofouling ensure longevity and reliability in harsh conditions. These materials also exhibit good thermal conductivity, making them suitable for heat exchange applications. The 70/30 alloy provides outstanding weldability, formability, and machinability, allowing easy customization and fabrication. Copper Nickel 70/30 Sheets and Plates also offer resistance to pitting, crevice corrosion, and stress corrosion cracking, enhancing durability and performance in diverse industries.
Because of their exceptional resistance to saline environments, copper nickel 70/30 sheets and plates are widely used in the marine industries for the production of condenser tubes, seawater piping systems, heat exchangers, and ship hulls. They are also used in power generation facilities, desalination plants, and offshore oil and gas platforms where corrosion resistance and durability are essential. These sheets are used in storage tanks, evaporators, and reactors in the chemical industry. They are also perfect for cooling circuits and hydraulic lines due to their superior heat conductivity and resistance to biofouling. Under demanding and high-pressure service conditions, these characteristics allow for dependable long-term performance.
