Based in Delhi, India, Kunj Sheets and Plates is a well-known producer and supplier of EN 24 sheets and plates. We cater to the automotive, aerospace, defence, and heavy engineering sectors and are renowned for our superior quality and precisely engineered products. High-strength alloy steel of EN 24 grade is renowned for its remarkable durability and resistance to wear. At Kunj, we make sure that our plates and sheets are tailored to our customers’ needs and satisfy strict quality standards. We are able to provide dependable and long-lasting products that are appropriate for high-performance applications in both Indian and foreign markets thanks to our state-of-the-art facilities and skilled workforce.
Steel alloyed with nickel, chromium, and molybdenum makes up EN 24 sheets and plates. 0.36–0.44% carbon, 0.45–0.70% manganese, 1.30–1.80% nickel, 0.90–1.40% chromium, and 0.20–0.35% molybdenum make up the typical composition. The mechanical characteristics include outstanding toughness and fatigue resistance, as well as a tensile strength of 850–1000 MPa and a yield strength of 680 MPa. This steel is appropriate for demanding applications needing durability under dynamic loads because it is heat-treatable and has high ductility, hardness, and shock resistance.
| Thickness | from 3mm up to as thick as 150mm |
|---|---|
| Size | from 2000 x 1000mm up to 4000 x 2000mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | -52° C |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | P | Mo | Mn | S | Cr | Si | Ni | |
| EN – 24 | .35 – .45 | .040 | .20 – .40 | .45 – .70 | .040 | .90 – 1.40 | .10 – .35 | 1.30 – 1.80 |
| Max Stress | 850-1000 n/mm2 | |
| Yield Stress | 680 n/mm2 Min | Up to 150mm LRS |
| 654 n/mm2 Min | 150 to 250mm LRS | |
| 0.2% Proof Stress | 665 n/mm2 Min | Up to 150mm LRS |
| 635 n/mm2 Min | 150 to 250mm LRS | |
| Elongation | 13% Min | (9% if cold drawn) |
| Impact KCV | 50 Joules Min | Up to 150mm LRS |
| 35 Joules Min | 150 to 250mm LRS | |
| Hardness | 248-302 HB |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 817M40 | EN24 | 4340 | 1.6582 |
EN24 sheets and plates offer many key benefits including exceptional strength and toughness, making them ideal for high-pressure applications. They exhibit excellent fatigue and wear resistance, providing durability in harsh environments. The high hardness and impact resistance of the alloy makes it suitable for use in critical applications such as shafts, gears and machine parts. EN 24 also provides excellent mechanical properties and can be heat treated to achieve desired mechanical properties. EN 24 is invaluable in the aerospace, automotive and industrial industries for its reliability, versatility and performance under extreme conditions.
Yes, we offer custom sizes for EN24 Sheet and Plates to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
EN 24 plates and sheets are frequently utilised in applications that call for extreme durability and strength. Typical applications include the production of automotive parts such as crankshafts, axles, shafts, and gears. Because of their fatigue strength, they are utilised for engine and structural components in aerospace. EN 24 is used in the defence industry for high-stress applications like parts for weapons. Additionally, it works well with forging dies, oil and gas tools, and heavy machinery. EN 24 is perfect for engineering components subjected to high levels of stress, impact, and wear because it can retain strength at high temperatures.
