Kunj Metal Industries provides premium Haynes 230 Sheets and Plates from Delhi, India, which are renowned for their exceptional resistance to oxidation and high temperature strength. The nickel-chromium-tungsten-molybdenum alloy Haynes 230 was designed to function dependably in extremely hot conditions. Performance and durability are important factors in industrial and aerospace applications where our sheets and plates are utilised. Kunj guarantees that every Haynes 230 product offers exceptional creep resistance, thermal stability, and corrosion resistance, making it perfect for demanding industrial applications. This is achieved through a focus on precision manufacturing and adherence to international quality standards.
About 57% nickel, 22% chromium, 14% tungsten, and 2% molybdenum make up Haynes 230. It provides exceptional strength and creep resistance at high temperatures, as well as exceptional oxidation resistance up to 1149°C. Mechanical characteristics include exceptional resistance to heat fatigue and a tensile strength of roughly 895 MPa. When exposed to high heat for an extended period of time, the alloy retains its structural integrity and dimensional stability. It is adaptable for fabrication and installation in difficult environments due to its low thermal expansion and good weldability.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloy 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
| STANDARD | Material No | UNS | Alloy |
| Haynes 230 | – | R30605 | 230 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Haynes 230 sheets and plates offer exceptional high temperature strength, outstanding oxidation resistance up to 2100°F (1150°C), and excellent carburizing resistance, making them ideal for demanding applications They exhibit creep resistance exhibiting excellent and long-term thermal stability, ensuring durability in extreme environments. These materials are very versatile and are used in gas turbines, heat exchangers, and chemical plants. Their excellent formability and weldability contribute to ease of manufacture. Additionally, the Haynes 230 withstands extreme heat cycles, making it reliable for applications requiring durability and operating at variable temperatures.
Gas turbines, combustion liners, transition ducts and afterburners are examples of high-temperature industrial systems that employ Haynes 230 Sheets and Plates. The alloy’s resistance to oxidation, nitridation, and carburisation ensures long-term performance in power plants and incinerators. Flame holders and turbine engine casings are examples of aerospace applications. It is utilised for retorts, muffles, and radiant tubes in metallurgical and heat treatment facilities. It is dependable in high-stress, high-cycle applications due to its resistance to thermal fatigue. Haynes 230 is also used in chemical processing settings with high temperatures and potent oxidising and reducing agents.
