Kunj Sheets and Plates is a premier Delhi-based manufacturer and supplier of high-quality industrial metals, such as Haynes 25 / L605 foil. Famed for their precision and durability, Kunj Sheets and Plates serves various industries by offering top-grade Haynes 25 foils that stand out for their exceptional heat and corrosion resistance. With modern manufacturing units and high-quality control measures, the company is able to deliver consistent excellence in each sheet and plate supplied. Kunj Sheets and Plates customers trust for consistent products conforming to demanding industrial standards.
Haynes 25 / L605 foil is a cobalt superalloy consisting mainly of about 55% cobalt, 20% chromium, 10% nickel, 15% tungsten, and traces of iron, manganese, carbon, and others. Such an unusual composition gives it high mechanical properties like high tensile strength, great creep resistance, and excellent corrosion and oxidation resistance at high temperatures. It has structural integrity under harsh conditions, giving it high-performance applications where durability and endurance are important.
| Standard | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
| STANDARD | Material No | EN Designation | UNS | Alloy |
| Haynes 25 / L605 | 2.4964 | CoCr20W15Ni | R30605 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Haynes 25 (L605) foil provides excellent high strength and oxidation resistance, making it ideal for harsh environments including aerospace and industrial applications in particular and excellent fighting strength resist corrosion in harsh environments such as sulfuric and hydrochloric acids ensuring long-term performance. The high creep and fatigue resistance of the alloy makes it suitable for high pressure applications. Also, its excellent weldability and formability enhance construction flexibility. Haynes 25’s ability to stabilize and toughen at temperatures up to 2000°F (1093°C) makes it versatile in a wide range of applications requiring high performance.
Haynes 25 / L605 foil has broad-based application in aerospace, power generation, and chemical processing due to its excellent resistance to heat, oxidation, and corrosion. Typical uses involve turbine blades, combustion chambers, heat exchangers, and gas turbine components. Its high-quality mechanical properties at high temperatures further find it applicable in exhaust valves, furnace components, and other severe environments. Foil’s strength and flexibility allow manufacturers to make precision parts that can tolerate rigorous operating conditions, providing reliability and performance.
