Kunj Metal Industries is a leading production and supplier of Haynes Sheets and Plates in Delhi, India, offering top-notch superalloy solutions to sectors that demand exceptional resistance to corrosion and high temperatures. Our Haynes products are designed for vital service applications in the chemical processing, marine, and aerospace sectors. We guarantee consistent performance and dependability by using sophisticated manufacturing techniques and stringent quality control procedures. For complex applications where thermal, structural, and chemical integrity are crucial, Kunj provides Haynes alloy sheets and plates in a range of grades and sizes.
High-performance alloys made of nickel or cobalt are known as Haynes alloys. Chromium, molybdenum, and tungsten are added for strength and resistance to corrosion. These plates and sheets have outstanding mechanical qualities, such as a tensile strength of over 850 MPa and superior resistance to oxidation at temperatures above 1,000°C. They are appropriate for high-stress situations because they are resistant to sulfidation, carburisation, and thermal fatigue. Even after extended exposure to harsh environments, their structural integrity and fabricability hold firm.
| Specification : | AMS 5608 / AMS 5609 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 188 (UNS R30188) |
| Grade | C | Mn | P | S | Si | Ni | Cr | Fe | W | B | Mo | Co |
| Haynes 188 | .05 – .15 | 1.25 max | .020 max | .015 max | .20 – .50 | 20.0 – 24.0 | 21.0 -23.0 | 3.0 max | 13.0 -15.0 | .015 max | .03 – .15 | – |
| Yield Strength | Tensile Strength | Elongation | ||
|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % |
| 65 | 446 | 140 | 963 | 55 |
| STANDARD | Material No | UNS | Alloy |
| Haynes 188 | – | R30605 | 188 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Haynes sheets and plates are invaluable for their exceptional high-temperature strength, oxidation resistance and durability in harsh environments. Constructed of advanced nickel alloys for excellent corrosion resistance, making them ideal for harsh conditions in space, chemical processing, and energy applications Their ability to maintain high mechanical temperature, combined with good weldability and formability ensures reliability and durability is also known because, ensuring excellent performance of mechanical products which requires more.
Because of their exceptional high-temperature capabilities, Haynes Sheets and Plates are extensively utilised in the aerospace industry for parts such as combustion chambers, engine casings, and afterburners. Additionally, they are used in marine engines, chemical processing reactors, and gas turbines where heat tolerance and corrosion resistance are crucial. Under cyclic heating in industrial furnaces and heat-treatment systems, Haynes alloys retain their mechanical characteristics. They are perfect for the petrochemical, power, and energy sectors due to their resistance to sulfidation and carburisation. In welding applications, where joint strength and thermal stability are crucial, these materials are also recommended.
