Kunj Sheets and Plates is a well-known manufacturer and supplier from Delhi, India, dealing in high-grade High Carbon Steel Plates. With a focus on excellence and customer satisfaction, we provide long-lasting, precision-crafted plates that can be used for numerous industrial purposes. Our state-of-the-art production facility and experienced team ensure strict adherence to international standards, making us the first choice across industries. We have a large clientele with customized solutions and quick delivery. At Kunj, we focus on innovation, reliability, and cost-effectiveness, so we are a reliable name in India’s High Carbon Steel Plates market.
High Carbon Steel Plates consist of 0.60% to 1.00% of carbon, in addition to manganese (0.30–0.90%) and minute amounts of silicon, sulfur, and phosphorus. This composition gives more hardness and strength. Mechanically, they have high tensile strength (about 800–1000 MPa), good abrasion resistance, and low ductility. They are capable of being hardened by heat treatment using quenching and tempering. But because of their brittleness over low carbon steel, they are less ductile and have lower weldability. All these characteristics render them ideal for use in their applications where durability and abrasion resistance are needed.
Standard : ASTM A830/ASME SA830
Thickness : 2mm – 600mm
Width : 1000mm – 3000mm
Length : 3000mm – 12000mm
| Grade | C(%)min-max | Si(%)min-max | Mn(%)min-max | P(%)max | S(%)max | Cr(%)min-max |
| C45 | 0.42-0.50 | 0.15-0.35 | 0.50-0.80 | 0.025 | 0.025 | 0.20-0.40 |
| Grade | Condition | Yield Strengtd R°(Mpa) | Tensile Strength Rm (Mpa) | Elon- gation A5(%) | Hardness HRC | Quenching Temperature (℃) | Benda- bility | Nominal Thickness,t 1.95mm≤t≤10.0mm | |
| Rolled | Annealed | ||||||||
| C45 | Rolled Annealed Water-quenched Oil quenched | 460 330 | 750 540 2270 1980 | 18 30 | 58 55 | 820 860 | Min.reco-mmended Bending radius (≤90°) | 2.0 ×t | 1.0×t |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
High Carbon Steel Plates offer several key advantages, including exceptional strength and hardness, making them ideal for heavy-duty applications. Their high tensile strength and wear resistance ensure durability in challenging environments, such as construction, mining, and manufacturing. These plates are highly resistant to abrasion and deformation, providing long-lasting performance. Despite their high hardness, they retain good machinability, allowing for precise cutting and shaping. High Carbon Steel Plates are cost-effective, offering superior value for industries requiring high-strength materials, and are ideal for applications that demand toughness and reliability.
Yes, we offer custom sizes for High Carbon Steel Sheet and Plates to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
| C45 EN 10083-2 Number:1.0503 | Comparison of steel grades | |
| JIS G 4051 | S 45 C | |
| DIN 17200 | C 45 | |
| NFA 33-101 | AF65-C 45 | |
| UNI 7846 | C 45 | |
| BS 970 | 070 M 46 | |
| UNE 36011 | C 45 k | |
| SAE J 403-AISI | 1042/1045 | |
High Carbon Steel Plates are widely utilized in industries necessitating excellent strength and wear resistance. Typical uses involve the production of cutting tools, blades, dies, springs, and wear-resistant parts for machinery. In the construction industry, they are applied in bearing structures and heavy equipment. Automotive industries employ such plates for components such as gears and axles. They are also in railways for track elements and mining for liners in crushing equipment. Their hardness makes them suitable for precision tools and agriculture tools. Kunj Sheets and Plates assures quality materials appropriate for harsh industrial and engineering conditions.
