Kunj Metal Industries is a well-known Delhi, India-based supplier of High Strength Steel Sheets and Plates, providing strong, high-performing materials for demanding mechanical and structural applications. Our high strength steels are designed to have good formability and weldability while offering greater yield and tensile strength than traditional mild steels. For buildings, machinery, and transportation equipment, these plates are perfect for reducing weight and increasing load-bearing capacity. Kunj offers specialised grades and thicknesses with uniform surface finish and mechanical qualities to satisfy particular industrial requirements.
In order to increase strength and toughness, high strength steel usually contains micro-alloying elements like titanium, niobium, and vanadium along with a low carbon content. Depending on the grade, these plates have yield strengths between 350 and more than 700 MPa, and their tensile strength can reach up to 900 MPa. Performance under high mechanical stress is made possible by the steels’ exceptional elongation and fracture resistance. They are appropriate for both static and dynamic loading conditions due to their structural integrity and weldability.
| Specification | High Tensile Plates |
|---|---|
| Production | Hot-Rolled (HR), Cold-Rolled (CR) |
| Thickness: | 3 MM to 250 MM |
| Width | 1000 MM to 3000 MM |
| Lengths: | up to 20 M |
| S | Cr | P | Al | C | Ni | Si | Mo | Mn |
|---|---|---|---|---|---|---|---|---|
| 0.005 max | 1.50 max | 0.0.20 max | 0.015 max | 0.20 max | 2.0 max | 0.80 max | 0.70 max | 1.70 max |
| Thickness milimeter | Rm MPa | Re MPa | A % |
|---|---|---|---|
| < 50 | 770 – 940 | 690 | 14 |
| > 50 ? 100 | 760 – 930 | 650 | 14 |
| > 100 | 710 – 900 | 630 | 14 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
High-strength steel sheets and plates offer many advantages, including improved durability and corrosion resistance, making them ideal for complex applications such as construction, automotive and mechanical interiors weight Increased configuration is offered, enabling lightweight energy-efficient design. The material’s ability to withstand high stresses and impacts enhances safety and reliability. High-strength steel also offers higher formability and weldability, making it more versatile. Additionally, it helps to reduce material costs by requiring less bulk while maintaining the required level of performance.
Structural engineering, construction equipment, and high-load industrial frameworks all make use of high-strength steel sheets and plates. They are extensively used in wind tower construction, earthmoving machinery, truck chassis, trailers, and shipbuilding. They are used by automakers to lighten vehicles without sacrificing safety. They are perfect for hydraulic systems, bridges, and cranes because of their exceptional durability and fatigue resistance. These plates are also chosen for the construction of offshore structures, pressure vessels, and lifting devices where cost and safety depend on the strength-to-weight ratio.
