Kunj Sheets and Plates is a leading Delhi-based manufacturer and supplier of high-quality Incoloy 800, 800H, and 800HT channels. With their reputation for robustness and accuracy, our products suit the varied industrial applications, delivering outstanding performance in extreme conditions. Dedicated to excellence, Kunj Sheets and Plates provides customized solutions, strict quality checks, and on-time delivery. Our Incoloy channels meet stringent international standards, making us a trusted partner in sectors like power generation, chemical processing, and aerospace. Choose Kunj for reliable, corrosion-resistant Incoloy channels that stand the test of time.
Incoloy 800 series primarily comprises nickel (30-35%), iron (bal.), and chromium (19-23%), with minor amounts of manganese, carbon, and aluminum. Incoloy 800H and 800HT variants have slightly higher carbon content for enhanced high-temperature strength. These tubes have outstanding mechanical properties such as tensile strength between 75,000 to 90,000 psi and yield strength about 30,000 to 50,000 psi with very good resistance to oxidation and carburization. The material is resistant to loss of strength and toughness even at high temperatures, so it is suitable for applications involving high temperatures.
Specifications : ASTM B408 / ASME SB408
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Incoloy 800, 800H, and 800HT channels offer several advantages, including exceptional resistance to oxidation, carburization, and thermal degradation at high temperatures. These alloys maintain strength and stability in extreme environments, making them ideal for applications in chemical processing, power plants, and heat exchangers. Incoloy 800H and 800HT variants provide enhanced creep strength and resistance to thermal fatigue, with 800HT offering superior stability at elevated temperatures. Additionally, these alloys exhibit excellent weldability, formability, and corrosion resistance, ensuring long-term reliability and durability in challenging industrial conditions.
Yes, we offer custom sizes for Incoloy 800 / 800H / 800HT Channel to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
Incoloy 800, 800H, and 800HT tubes find extensive use in applications involving superior corrosion resistance and high-temperature strength. They are best suited for heat exchangers, furnace parts, gas turbines, and chemical processing plant equipment. Their high endurance against oxidation, carburization, and thermal fatigue makes them well suited for power generation plants, petrochemical manufacturing, and aerospace. The 800H and 800HT versions are particularly desired when long-term exposures to higher temperatures are involved. These channels are also used in nuclear reactors and pressure vessels, reflecting their diversity in high-stress, critical applications.
