Incoloy 825 Sheets and Plates

Based in Chennai, India, Kunj Sheets and Plates is a reputable producer and supplier of high-grade Incoloy 825 Sheets and Plates. Our speciality is offering corrosion-resistant alloys that satisfy the demanding specifications of different sectors. Our Incoloy 825 Sheets and Plates are renowned for their exceptional durability in harsh conditions, exceptional strength, and outstanding resistance to oxidising and reducing acids. These products, which come in a variety of thicknesses, sizes, and finishes, are perfect for use in the oil and gas, marine, chemical processing, and pollution control sectors. Kunj ensures adherence to international standards, providing reliable materials for high-performance engineering needs.

Incoloy 825 Sheets Dealer in Chennai, Incoloy 2.4858 Plates Supplier in Chennai, Incoloy 825 Sheets in Chennai, 825 Incoloy Plates Size Chart, Incoloy 825 Sheet Price in India, Incoloy 825 Plates Supplier in Chennai, 825 Incoloy Sheet Stockist in India, 825 Incoloy Alloy Sheets and Plates Exporter in India, Incoloy 825 Sheet Stockist in Chennai, Incoloy Plates Supplier in India

Incoloy 825 Cold Rolled Plates

Incoloy 825 Hot Rolled Plates

Incoloy 825 Clad Sheets and Plate

Nickel-iron-chromium alloys with notable molybdenum, copper, and titanium additions make up Incoloy 825 Sheets and Plates. About 38–46% nickel, 19.5–23.5% chromium, 2.5–3.5% molybdenum, 1.5–3% copper, and 0.6–1.2% titanium make up the typical composition. These elements improve its ability to withstand a variety of corrosive conditions. The alloy has a minimum elongation of 30%, a yield strength of about 220 MPa, and a tensile strength of about 585 MPa. Incoloy 825 is appropriate for demanding structural and pressure applications under challenging chemical conditions because it maintains strength at high temperatures and provides exceptional weldability and formability.

Incoloy 825 Sheets and Plates Specification

Specifications:	ASTM / ASME SB 168, ASTM / ASME SB 424 , ASTM / ASME SB 443
Thickness:	4 mm To 100 mm
Length:	2000mm, 2438mm, 3000mm, 5800mm, 6000mm,12000mm，or as required
Width:	40mm-600mm, 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,or as required
Grade	800/ 800H/ 800HT/ 825
Application	Building industry,architectural decoration,elevators,building doors,panels and so on.
Standard:	ASTM，AISI，JIS，GB， DIN，EN
Surface:	BA，2B，NO.1，NO.4，4K，HL，8K
Certification:	ISO, SGS，BV
Technique:	Cold Rolled Hot Rolled
Finish	Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form	Sheets, Plates, Coils, Slatting Coils, Perforated Coils

Incoloy 825 Sheet and Plate Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr	Al	Ti
825	0.05 max	1.00 max	0.5 max	0.03 max	1.50 – 3.00	22.00 min	38.00 – 46.00	19.50 – 23.50	0.02 max	0.06 – 1.20

Alloy 825 Sheet and Plate Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
825	8.14 g/cm3	1400 °C (2550 °F)	Psi – 80,000 , MPa – 550	Psi – 32,000 , MPa – 220	30 %

Equivalent Grades for 825 Incoloy Sheet and Plates

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN	OR
Incoloy 825	2.4858	N08825	NCF 825	NA 16	ЭП703	NFE30C20DUM	NiCr21Mo	XH38BT

825 Incoloy Sheets Price in India, 825 Incoloy Hot Rolled Weight Chart, Incoloy N08825 Cold Rolled Supplier in Chennai, Stockist of Incoloy 825 Alloy Cold Rolled Sheets in India, 825 Incoloy Perforated Sheet Supplier in India, Incoloy 825 Perforated Plates Price List in Chennai, Alloy Perforated Plates Supplier in India, Incoloy 825 Chequered Plates Exporter in Chennai, Incoloy Alloy 825 Polished Plates Exporter in India, 825 Incoloy Perforated Plates Exporter in Chennai, 825 Incoloy Sheet and Plate in India

Weight Chart of 825 Incoloy Alloy Sheets and Plates

Thickness	Plate Weight per Unit Area	Density
3/16 inches	0.06000 lbs/in²42.184176 kg/m²	0.315 lbs/in³8.72 g/cm³
1/4 inches	0.08 lbs/in²56.245568 kg/m²	0.315 lbs/in³8.72 g/cm³
3/8 inches	0.121 lbs/in²85.0714216 kg/m²	0.315 lbs/in³8.72 g/cm³
1/2 inches	0.161 lbs/in²113.1942056 kg/m²	0.315 lbs/in³8.72 g/cm³
5/8 inches	0.196 lbs/in²137.8016416 kg/m²	0.315 lbs/in³8.72 g/cm³
3/4 inches	0.235 lbs/in²165.221356 kg/m²	0.315 lbs/in³8.72 g/cm³
7/8 inches	0.274 lbs/in²192.6410704 kg/m²	0.315 lbs/in³8.72 g/cm³
1 inches	0.313 lbs/in²220.0607848 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/4 inches	0.391 lbs/in²274.9002136 kg/m²	0.315 lbs/in³8.72 g/cm³
1 1/2 inches	0.47 lbs/in²330.442712 kg/m²	0.315 lbs/in³8.72 g/cm³
1 3/4 inches	0.549 lbs/in²385.9852104 kg/m²	0.315 lbs/in³8.72 g/cm³
2 inches	0.627 lbs/in²440.8246392 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/4 inches	0.705 lbs/in²495.664068 kg/m²	0.315 lbs/in³8.72 g/cm³
2 1/2 inches	0.784 lbs/in²551.2065664 kg/m²	0.315 lbs/in³8.72 g/cm³
2 3/4 inches	0.862 lbs/in²606.0459952 kg/m²	0.315 lbs/in³8.72 g/cm³
3 inches	0.941 lbs/in²661.5884936 kg/m²	0.315 lbs/in³8.72 g/cm³

Incoloy 825 Plate Size

Incoloy 825 Plates STOCKED SIZES
SIZE	ALLOY 825	SIZE
.125″	X	3.18mm
.134″		3.40mm
.156″	X	3.96mm
.187″	X	4.75mm
.250″	X	6.35mm
.312″	X	7.92mm
.375″	X	9.53mm
.500″	X	12.7mm
.625″	X	15.9mm
.750″	X	19.1mm
.875″		22.2mm
1″	X	25.4mm
1.125″		28.6mm
1.250″	X	31.8mm
1.500″	X	38.1mm
1.750″	X	44.5mm
2″	X	50.8mm
2.500″	X	63.5mm
3″		76.2mm

If You Are Looking To Buy High Quality Piping Products ?

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Largest Incoloy 825 Sheet and Plates Manufacturer and Exporter in Chennai, India

Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.

DIN 2.4858 Incoloy Clad Sheets Distributor in India, 825 Incoloy Perforated Plates Supplier in Chennai, 825 Incoloy Perforated Sheet Weight Chart, Incoloy 825 Plate Exporter in India, 825 Incoloy Polished Sheets Manufacturer in Chennai, Incoloy 825 Shim Sheet and Plate Price List in Chennai, 825 Incoloy Chequered Plates Sizes in mm, Incoloy Alloy 825 Hot Rolled Plate Distributor in Chennai, 825 Incoloy Sheets and Plates India

Incoloy 825 sheets and plates have many advantages, making them ideal for complex applications. Anti-corrosion properties, especially in acid and sulfur environments, ensure exceptional durability. The high strength and excellent fatigue resistance of the compound ensures reliability under stress. Incoloy 825 maintains high thermal integrity and provides excellent weldability. It also provides outstanding compression resistance against stress corrosion cracking and pitting. These features make Incoloy 825 sheets and plates ideal for use in the pharmaceutical, marine environment, aerospace and nuclear industries, providing unparalleled performance and longevity

Types of Incoloy 825 Sheet and Plates

UNS N08825 Incoloy Plates Manufacturer in Chennai, 825 Incoloy Plates and Sheets Chennai, Incoloy 825 Mirror Finish Plates Supplier in Chennai, 825 Incoloy Polished Plates Exporter in India, Incoloy 825 Alloy Chequered Plates Price List in Chennai, Incoloy 825 Cold Rolled Plate Distributor in Chennai, 825 Incoloy Clad Plates and Sheets Supplier in Chennai, Incoloy 825 Sheet and Plate Distributor in India, 825 Incoloy Perforated Plate Sizes in mm

Are Custom Sizes Available for Incoloy 825 Sheet and Plates?

Yes, we offer custom sizes for Incoloy 825 Sheet and Plates to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@kunjsheetsplates.com.

Customer Support

Largest Inventory

On Time Delivery

Quality Assurance

Competitive Pricing

Application Industry of Incoloy 825 Sheet and Plates

Industries that need to withstand extremely corrosive conditions frequently use Incoloy 825 Sheets and Plates. Because of their remarkable resistance to phosphoric and sulphuric acids, they are utilised in chemical processing for heat exchangers, pickling apparatus, and acid production systems. Because of their resilience in brine and seawater, the oil and gas sector uses them in offshore platforms, piping, and tubing. Incoloy 825 is also essential for corrosion resistance in pollution control systems, such as ducting and scrubbers. These plates are also used in waste treatment and nuclear fuel reprocessing facilities because they are stable in reducing and oxidising conditions.
