Top-grade Inconel 601 Foils are available from Kunj Sheets and Plates, a well-known manufacturer and supplier in Chennai, India, for businesses needing high-performance materials in harsh corrosive and thermal conditions. Our Inconel 601 Foils, which are made in accordance with international standards, come in a range of thicknesses and widths and demonstrate exceptional oxidation resistance, even at high temperatures. With a strong emphasis on quality, accuracy, and prompt delivery, Kunj makes sure that these foils satisfy the exacting specifications of industries like power generation, petrochemicals, heat treatment, and aerospace, providing customers with exceptional long-term performance, workability, and durability under the most trying circumstances.
Nickel (58–63%), chromium (21–25%), and iron (balance) make up the majority of Inconel 601 Foils, with trace amounts of silicon, carbon, and aluminium. Excellent resistance to high-temperature oxidation and scaling is provided by this combination. In addition to having a high creep resistance and structural stability at temperatures above 1000°C, the foils have a tensile strength of about 620 MPa and a yield strength of about 310 MPa. Inconel 601 is appropriate for forming, welding, and long-term use in thermally demanding environments because it retains good mechanical strength and ductility at both room temperature and higher temperatures.
| Standards | ASTM B168 / ASME SB168 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 601 foils offer several advantages, making them ideal for high-temperature and high-stress applications. They exhibit outstanding oxidation and carburization resistance, ensuring durability in extreme environments. The alloy’s excellent resistance to thermal creep and high tensile strength make it reliable in aerospace, chemical, and industrial applications. Inconel 601 also provides superior weldability, maintaining strength and stability even after fabrication. Its ability to retain mechanical properties at elevated temperatures enhances performance, while its resistance to sulfur compounds further extends its lifespan in harsh, corrosive environments, reducing maintenance costs and downtime.
Yes, we offer custom sizes for Inconel 601 Foils to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@kunjsheetsplates.com.
| Thickness | Foil Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Inconel 601 Industries that require oxidation resistance and strength at high temperatures frequently use foils. They are utilised in exhaust ducts, turbine engine parts, and heat shields in the aerospace industry. Additionally, Inconel 601 Foils are essential in industrial furnaces, where they are used in retorts, muffles, and radiant tubes. They are used in thermal processing equipment, insulation wraps, and reformer and superheater tubes in petrochemical and power generation facilities. These foils provide durability, thermal stability, and corrosion resistance in extremely harsh environments, making them perfect for thermal spray masking, electrical resistance elements, and catalyst support grids.
