Renowned Chennai, India-based manufacturer and supplier Kunj Sheets and Plates specialises in providing high-grade Inconel 625 Foils made to withstand extreme heat and corrosion. Our Inconel 625 Foils, which come in a range of thicknesses and widths and are manufactured in compliance with international standards, are renowned for their exceptional strength and flexibility. These foils are expertly designed for vital uses in a variety of sectors, including power generation, chemical processing, marine, and aerospace. At Kunj, we’re dedicated to providing robust, high-performing solutions that are suited to our clients’ exacting requirements worldwide.
Nickel (58% minimum), chromium (20–23%), molybdenum (8–10%), and niobium (3.15–4.15%) make up the majority of Inconel 625 Foils, with trace amounts of iron, cobalt, and other elements. Particularly in chemical and marine environments, this composition offers remarkable corrosion resistance. The foils have a yield strength of about 414 MPa and a tensile strength of about 827 MPa. High-performance, high-pressure, and high-heat applications can benefit from Inconel 625 Foils’ exceptional fatigue and creep resistance, resistance to oxidation and pitting, and maintenance of excellent mechanical qualities over a broad temperature range.
| Standards | ASTM B168 / ASME SB168 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Inconel 625 foils offer several key advantages, making them ideal for demanding applications. They provide exceptional resistance to high-temperature oxidation, corrosion, and carburization, ensuring longevity in harsh environments. The alloy’s excellent fatigue and creep resistance at elevated temperatures make it reliable in stress-prone situations. Inconel 625 also boasts excellent weldability and toughness, allowing for easy fabrication and adaptability. Its outstanding strength-to-weight ratio and resistance to various corrosive media make it highly suitable for industries such as aerospace, chemical processing, marine, and power generation. These properties ensure superior performance and durability.
Yes, we offer custom sizes for Inconel 625 Foils to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@kunjsheetsplates.com.
| Thickness | Foil Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
Industries that need to be able to withstand high temperatures and corrosive environments frequently use Inconel 625 Foils. They are utilised in exhaust systems, jet engine insulation, and heat shields in the aerospace sector. Because of their exceptional resistance to corrosion caused by chloride, the marine industry depends on these foils for seawater components, submarine hulls, and marine exhausts. They are used in scrubbers, ducting, and vessel lining in the chemical processing industry. Additionally, Inconel 625 Foils find use in nuclear applications, power plants, and pollution control systems. Their thin, flexible design makes it simple to fabricate parts that need to be precise and perform well in harsh conditions.
