Premium Monel 400 Coil and Slitting Coil are available from Chennai, India-based Kunj Sheets and Plates, a reputable manufacturer and supplier, to satisfy the exacting requirements of different industries. Monel 400 is renowned for its remarkable strength and resistance to corrosion, making it a perfect option for industrial, chemical, and marine applications. At Kunj, we guarantee accurate slitting and exceptional quality in each coil, supported by a dedication to timely delivery and international standards. We are a go-to source for trustworthy Monel 400 solutions because of our large inventory and customer-focused service, which have won us the trust of customers both in India and abroad.
The typical composition of Monel 400, a nickel-copper alloy, is 63% nickel and 30–34% copper, with trace amounts of silicon, carbon, manganese, and iron. It provides exceptional corrosion resistance, particularly in acidic and salty environments. In addition to having good thermal conductivity and toughness over a broad temperature range, Monel 400 coils have tensile strengths of 480–620 MPa, yield strengths of about 170 MPa, and elongation of up to 35%. The alloy is appropriate for critical engineering applications because it is non-magnetic at room temperature and retains mechanical stability under high pressure.
Specifications : ASTM B127 / ASME SB127
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness : 0.3 mm to 120 mm
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Finish : Hot rolled (HR), Cold rolled coils (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form : Plain Coils, Shim Coils, Strip
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel 400 coil/slitting coil offers excellent corrosion resistance, particularly in acidic environments, making it ideal for marine, chemical, and oil industries. Even at elevated temperatures, it provides high strength, toughness, and durability. The material’s resistance to pitting and stress-corrosion cracking ensures long-term reliability. Its ease of fabrication and weldability make it suitable for various applications, offering versatility in industrial processes. Monel 400 coil/slitting coil is an excellent choice for demanding environments due to its superior mechanical properties and corrosion resistance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Because of their great resistance to saline and acidic environments, Monel 400 coils and slitting coils are widely used in the chemical processing, hydrocarbon refining, and marine engineering industries. They are used in the construction of fuel tanks, seawater piping systems, pump shafts, valves, and heat exchangers. Monel 400 coils are prized for their conductivity and longevity in the electronics and aerospace industries. They are also utilised in the manufacturing of condensers, flexible metal hoses, and cladding for equipment used in oil refineries. In demanding industrial settings, their corrosion-resistant qualities guarantee a long service life and dependable performance.
