Kunj Sheets and Plates is your go-to manufacturer and supplier of **Monel 400 Foils** right here in Chennai, India. Monel 400 is a solid solution alloy that mainly consists of nickel and copper, and it’s well-known for its outstanding resistance to seawater, acids, and alkalis. Our Monel 400 foils are crafted with precision for applications that demand high strength, exceptional corrosion resistance, and great thermal conductivity. We offer these foils in a variety of thicknesses and custom widths, all while adhering to strict industry standards. At Kunj, we pride ourselves on delivering consistent quality, quick turnaround times, and personalized solutions, making our Monel 400 foils perfect for critical sectors like marine, chemical, and electronics industries.
**Monel 400 Foils** are made up of about **63% nickel**, **30–34% copper**, along with trace amounts of **iron**, **manganese**, and **carbon**. This alloy is renowned for its **excellent corrosion resistance**, especially in **marine** and **acidic** environments. It boasts a **tensile strength of 480–620 MPa**, a **yield strength of 170 MPa**, and an **elongation of around 35%**. Monel 400 foils are tough, easy to weld, and maintain stability across a wide temperature range. Their formability and thermal stability make them ideal for intricate fabrication and high-stress applications where reliability is a must.
| Standards | ASTM B127 / ASME SB127 |
| Thickness | 0.3 – 10.0mm & AS PER CUSTOMER’S REQUIREMENT |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm & AS PER CUSTOMER’S REQUIREMENT. |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm & AS PER CUSTOMER’S REQUIREMENT. |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard AS PER CUSTOMER’S REQUIREMENT. |
| Test Certificate | Chemical test, Fitting test, Alloy test, Radiography test, Macro and micro-test, Hydrostatic test, Impact test. |
| Finish | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled (HR), Cold rolled (CR), SATIN (Met with Plastic Coated) etc. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Monel DIN 2.4360 Foils offer outstanding advantages, including excellent corrosion resistance in seawater, acidic, and alkaline environments, making them ideal for marine and chemical applications. They possess high mechanical strength and durability, ensuring long-lasting performance under extreme conditions. Monel 400 foils maintain stability across a wide temperature range, providing reliable functionality in high-temperature settings. Their excellent resistance to stress corrosion cracking and pitting enhances their dependability in critical applications. Easy to fabricate and weld, these foils are versatile for use in diverse industries, including aerospace, marine, chemical processing, and electrical systems.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel 400 | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
**Monel 400 Foils** are made up of about **63% nickel**, **30–34% copper**, along with trace amounts of **iron**, **manganese**, and **carbon**. This alloy is renowned for its **excellent corrosion resistance**, especially in **marine** and **acidic** environments. It boasts a **tensile strength of 480–620 MPa**, a **yield strength of 170 MPa**, and an **elongation of around 35%**. Monel 400 foils are tough, easy to weld, and maintain stability across a wide temperature range. Their formability and thermal stability make them ideal for intricate fabrication and high-stress applications where reliability is a must.
