Based in Chennai, India, Kunj Sheets and Plates is a well-known producer and supplier of premium Nickel Alloy 200 Coils and Slitting Coils. We provide precisely engineered products with outstanding thermal conductivity, corrosion resistance, and purity. Applications needing dependable performance in challenging chemical and industrial settings are best suited for our Nickel 200 coils. We cater to a variety of industries, such as electronics, chemical processing, and the marine sector, with an emphasis on quality, customisation, and prompt delivery. With products that guarantee longevity, effectiveness, and a long service life, Kunj Sheets and Plates is dedicated to fulfilling international standards.
With trace amounts of iron, carbon, manganese, silicon, and copper, Nickel Alloy 200 Coils/Slitting Coils are made up of 99.6% pure nickel. Excellent resistance to reducing agents and caustic alkalis is provided by this high-purity composition. The alloy has good elongation and ductility, a yield strength of about 148 MPa, and a tensile strength of about 462 MPa. Additionally, nickel 200 remains stable in high-temperature and cryogenic settings. It is appropriate for specific industrial and electrical applications because of its exceptional thermal and electrical conductivity, low gas content, and magnetic qualities.
| Specification | ASTM B162 / ASME SB 162 |
|---|---|
| Thickness | Plate 0125″ to 5.00″ / Sheets 008″ to .0125″ |
| Sheet / Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheet / Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Sheets Hardness | Half Hard, Quarter Hard, Soft, Hard, Spring Hard |
| Plate / Sheets Size | 15NB to 150NB In |
| Tempers | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Coils Thickness | 0.3 mm to 120 mm |
| Coils Length | AS PER CUSTOMER’S REQUIREMENT |
| Form | Sheets, Plates, Coils, Strips, Circle, Ring, Disc, Foils |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Steel Coil | Size (mm) | Weight per Coil (Kg) | Size(mm) | Weight per Coil (Kg) |
|---|---|---|---|---|
| Nickel Alloy 200 Coil | 4000 x 2000 x 2.0 | 136.0 | 3000 x 1500 x 5.0 | 191.0 |
| Nickel Alloy 200 Coil | 4000 x 2000 x 3.0 | 204.0 | 4000 x 2000 x 5.0 | 340.0 |
| Nickel Alloy 200 Coil | 2500 x 1250 x 4.0 | 106.0 | 2500 x 1250 x 6.0 | 159.0 |
| Nickel Alloy 200 Coil | 3000 x 1500 x 4.0 | 153.0 | 3000 x 1500 x 6.0 | 230.0 |
| Nickel Alloy 200 Coil | 4000 x 2000 x 4.0 | 272.0 | 4000 x 2000 x 6.0 | 408.0 |
| Nickel Alloy 200 Coil | 2500 x 1250 x 5.0 | 133.0 |
Nickel Alloy 200 coil/slitting coil has many advantages, such as good corrosion resistance, especially in alkaline and acidic environments. Its high electrical thermal conductivity makes it ideal for electronics and heat exchangers. The alloy’s excellent mechanical properties, such as high tensile strength and ductility, provide stability in harsh environments. Nickel 200 also exhibits excellent weldability and formability, making it easy to use in a variety of industrial applications. Its resistance to oxidation at high temperatures and resistance to harsh chemicals further increases its value in industries such as chemical manufacturing and aerospace
Industries that require high conductivity and corrosion resistance frequently use nickel alloy 200 coils and slitting coils. They are used in reactors, heat exchangers, and the manufacturing of caustic soda in the chemical and petrochemical industries. Because of their superior conductivity, the electrical industry uses them for electronic connectors, terminals, and battery components. They are also appropriate for the manufacturing of synthetic fibres, food processing machinery, and marine hardware. Nickel 200 coils are also utilised in plating processes, pharmaceuticals, and aerospace. Their adaptability and dependability in demanding settings are guaranteed by their capacity to function in both cryogenic and high-temperature settings.
