Based in Chennai, India, Kunj Sheets and Plates is a well-known producer and supplier of nickel alloy 200 sheets and plates. Kunj is renowned for their precision engineering and dedication to quality, providing high-performance nickel alloy materials designed for demanding industrial applications. Their Nickel 200 sheets and plates are perfect for use in the power generation, marine, and chemical processing industries because of their exceptional resistance to oxidation and corrosion. With cutting-edge facilities, skilled workers, and a commitment to international standards, Kunj guarantees dependable and long-lasting products that satisfy customer demands both domestically and internationally while offering unparalleled performance under demanding service conditions.
Commercially pure nickel (99.6%) is used to make Nickel Alloy 200 Sheets and Plates, which have exceptional electrical and thermal conductivity. Even at below-freezing temperatures, they show remarkable ductility and toughness, with a tensile strength of roughly 380 MPa and a yield strength of roughly 105 MPa. The alloy can withstand a wide range of corrosive conditions, particularly neutral salts and alkalis. It has good magnetostrictive qualities and excellent welding and fabrication capabilities. Because of these qualities, Nickel 200 is perfect for use in high-temperature processing systems and chemically aggressive environments.
| Specification | ASTM B 906/ASME SB 906, ASME Code Cases 1827 and N-253, SAE/AMS 5540, BS 3072NA14 and 3073NA14, DIN 17750, ISO 6208, EN 10095, MIL-DTL-23228. |
|---|---|
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard |
| standards and approvals |
|
| Plasma profiles | As per customer’s drawings |
| Value added services | Laser cutting, Waterjet cutting, Plasma cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing. |
| VAS |
|
| Packing | Bundles with waterproof cloth outside or plywood box |
| Test | UT, SGS testing, TUV etc |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | —2 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Nickel Alloy 200 sheets and plates offer exceptional corrosion resistance, particularly against alkalis, acids, and other harsh environments. Known for their excellent weldability and formability, they maintain good mechanical properties at low and high temperatures. The alloy exhibits high strength and durability, making it ideal for chemical processing, aerospace, and marine applications. Its excellent thermal and electrical conductivity ensures reliable performance in various industrial applications. Its non-magnetic properties add to its versatility, especially in sensitive equipment.
| Nickel Gauge Width and Length | Weight Lbs. per Sq. Ft. | Estimated Weight per Sheet |
|---|---|---|
| 7 ga. (.1874″) x 48 x 120 | 7.871 | 314.8 |
| 10 ga. (.135″) x 48 x 120 | 5.670 | 226.8 |
| 11 ga. (.120″) x 36 x 120 | 5.040 | 151.2 |
| 11 ga. (.120″) x 48 x 96 | 5.040 | 161.3 |
| 11 ga. (.120″) x 48 x 120 | 5.040 | 201.6 |
| 11 ga. (.120″) x 48 x 144 | 5.040 | 241.9 |
| 11 ga. (.120″) x 60 x 96 | 5.040 | 252.0 |
| 12 ga. (.105″) x 36 x 120 | 4.410 | 132.3 |
| 12 ga. (.105″) x 48 x 120 | 4.410 | 176.4 |
| 12 ga. (.105″) x 60 x 120 | 4.410 | 220.5 |
| 14 ga. (.075″) x 36 x 120 | 3.150 | 94.50 |
| 14 ga. (.075″) x 48 x 120 | 3.150 | 126.0 |
| 16 ga. (.060″) x 36 x 120 | 2.520 | 75.60 |
| 16 ga. (.060″) x 48 x 96 | 2.520 | 80.64 |
| 16 ga. (.060″) x 48 x 120 | 2.520 | 100.8 |
| 16 ga. (.060″) x 60 x 120 | 2.520 | 126.0 |
| 18 ga. (.048″) x 36 x 120 | 2.016 | 60.48 |
| 18 ga. (.048″) x 48 x 120 | 2.016 | 80.64 |
| 20 ga. (.036″) x 36 x 120 | 1.512 | 45.36 |
| 20 ga. (.036″) x 48 x 120 | 1.512 | 60.48 |
| 22 ga. (.030″) x 36 x 120 | 1.260 | 37.80 |
| 22 ga. (.030″) x 48 x 96 | 1.260 | 40.32 |
| 22 ga. (.030″) x 48 x 120 | 1.260 | 50.40 |
| 24 ga. (.024″) x 36 x 120 | 1.008 | 30.24 |
| 24 ga. (.024″) x 48 x 120 | 1.008 | 40.32 |
| 26 ga. (.018″) x 36 x 120 | .7560 | 22.68 |
| 26 ga. (.018″) x 48 x 120 | .7560 | 30.24 |
| 28 ga. (.015″) x 36 x 120 | .6300 | 18.90 |
In industries where exceptional corrosion resistance and purity are essential, nickel alloy 200 sheets and plates are widely used. Electroplating tanks, caustic handling systems, chemical processing equipment, and synthetic fibre manufacturing are examples of common applications. Because of their superior thermal and electrical conductivity, they are also used in food processing, electronics manufacturing, and marine and offshore engineering. Particularly in settings subjected to high temperatures and caustic substances, these sheets and plates are ideal for use in heat exchangers, pressure vessels, and nuclear reactor components. They are a vital component in high-stress industrial environments due to their robustness and simplicity of fabrication.
