One of the top producers and suppliers of premium stainless steel 301 angles is Kunj Sheets and Plates, which is based in Chennai, India. Kunj is renowned for providing high-performance stainless steel products and specialises in creating structural elements that are mechanically robust and resistant to corrosion, all while catering to industry-specific requirements. The company’s stainless steel 301 angles are designed to be strong, long-lasting, and have exceptional forming properties. Kunj Sheets and Plates, which serves industries like manufacturing, transportation, automotive, and construction, guarantees that every product satisfies exacting quality standards and specifications. They have established a solid reputation in both domestic and international markets thanks to their dependable services and tailored solutions.
Austenitic stainless steel 301 has a relatively low carbon content and roughly 16–18% chromium and 6–8% nickel. Because of its composition, it has excellent strength and resistance to corrosion, especially in mildly corrosive environments. It has an elongation of roughly 40%, a yield strength that begins at about 275 MPa, and a tensile strength of up to 760 MPa (when cold-worked). Through cold forming, 301’s exceptional work-hardening qualities boost strength. It is perfect for load-bearing and structural applications due to its mechanical performance, good ductility, and weldability.
| Specifications | ASTM A276 / ASME SA276 |
|---|---|
| Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Angles Size | 20mm to 200mm |
| Angle Thickness | 3mm to 12mm |
| Angles Length | Upto 6 Meters Long |
| Angles Types | Equal, Unequal, L Angle, Equal Leg Angle, Unequal Leg Angle, Hot Rolled Angle, Angle |
| ELEMENT | C | Mn | P | S | Si | Cr | Ni | N |
|---|---|---|---|---|---|---|---|---|
| SS 301 | 0.150 max | 2.00 max | 0.045 max | 0.030 max | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | 0.10 |
| SS 301L | 0.03 max | 2.00 max | 0.045 max | 0.030 max | 1.00 | 16.00 – 18.00 | 6.00 – 8.00 | 0.02 |
| Grade | Tensile Strength ksi (min.) | Yield Strength 0.2% ksi (min.) | Elongation -% in 50 mm (min.) |
|---|---|---|---|
| SS 301 | 185 | 140 | 9 |
| SS 301L | 550 | 220 | 45 |
| STANDARD | WERKSTOFF NR. | UNS | JIS |
|---|---|---|---|
| SS 301 | 1.4310 | S30100 | SUS 301 |
| SS 301L | – | S30103 | SUS 301L |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless steel 301 Angle provides excellent corrosion resistance, especially in bright environments, making it suitable for outdoor marine applications. It has consistency and can easily be shaped. The alloy provides high tensile strength and moderate hardness, ensuring durability and structural integrity. It also exhibits excellent fatigue resistance and easily cracks under stress, making it ideal for use in the industrial and construction industries In addition to stainless steel 301 Angle retains its properties in environments is extremely hot, providing versatility and reliability.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Because of their exceptional strength-to-weight ratio and resistance to corrosion, stainless steel 301 angles are used extensively in a variety of industries. They offer structural support for architectural designs, bridges, and frameworks in building and infrastructure projects. They are used in parts like railings and reinforcements in the automotive industry that need to be extremely strong and lightweight. They are used in brackets, frames, and body structures in the railway and transportation industries. Additionally, they are appropriate for equipment exposed to mildly corrosive environments, storage systems, and marine hardware. 301 angles are perfect for fabrication, framing, and mechanical assemblies under dynamic loads because of their durability and formability.
