One of the top producers and suppliers of premium stainless steel 304L sheets and plates is Kunj Sheets and Plates, which is based in Chennai, India. Kunj, which serves the chemical processing, pharmaceutical, food production, and construction industries, is renowned for its precision engineering and unwavering dedication to quality. The low-carbon version of 304, stainless steel 304L, has superior weldability and corrosion resistance. Kunj effectively serves both domestic and international clients by guaranteeing superior surface finish, durability, and dimensional accuracy in its 304L sheets and plates through sophisticated manufacturing capabilities and strict quality control.
About 18–20% chromium, 8–12% nickel, and no more than 0.03% carbon are present in stainless steel 304L, which helps avoid carbide precipitation when welding. It provides exceptional resistance to corrosion, particularly in environments that are chloride-rich and mildly acidic. The alloy’s elongation is approximately 40%, its yield strength is 170 MPa, and its tensile strength is approximately 485 MPa. Even in corrosive industrial settings, 304L retains exceptional formability, toughness, and cleanliness, which makes it perfect for welding and fabrication applications without the need for post-weld annealing.
| Standard | ASTM A240, ASME SA240 |
| Thickness | 0.1mm to 12 mm Thk |
| Sheet/Plate Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Surface | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sandblast, Brush, etching. |
| Finish | Hot rolled (HR), Cold rolled (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated), Galvanized etc. |
| Grade | C | Ni | Si | N | S | Mn | P | Cr | Mo | |
| SS 304L | min. | – | 8.0 | – | – | – | – | – | 18.0 | – |
| max. | 0.030 | 12.0 | 0.75 | 0.10 | 0.030 | 2.0 | 0.045 | 20.0 | ||
| Grade | Tensile Strength (MPa) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (MPa) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS 304L | 485 | 40 | 170 | 92 | 201 |
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| SS 304L | S30403 | 1.4306/1.4307 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 | SUS 304L | 304S11 | 03Х18Н11 |
Grade | Density of ss304 in kg/m3 | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
304L | 8000 | 193 | 17.2 | 17.8 | 18.4 | 16.2 | 21.5 | 500 | 720 |
| Thickness | Plate Weight per Unit Area | Density |
|---|---|---|
| 3/16 inches | 0.06000 lbs/in²42.184176 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/4 inches | 0.08 lbs/in²56.245568 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/8 inches | 0.121 lbs/in²85.0714216 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1/2 inches | 0.161 lbs/in²113.1942056 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 5/8 inches | 0.196 lbs/in²137.8016416 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3/4 inches | 0.235 lbs/in²165.221356 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 7/8 inches | 0.274 lbs/in²192.6410704 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 inches | 0.313 lbs/in²220.0607848 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/4 inches | 0.391 lbs/in²274.9002136 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 1/2 inches | 0.47 lbs/in²330.442712 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 1 3/4 inches | 0.549 lbs/in²385.9852104 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 inches | 0.627 lbs/in²440.8246392 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/4 inches | 0.705 lbs/in²495.664068 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 1/2 inches | 0.784 lbs/in²551.2065664 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 2 3/4 inches | 0.862 lbs/in²606.0459952 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
| 3 inches | 0.941 lbs/in²661.5884936 kg/m² | 0.315 lbs/in³8.72 g/cm³ |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 304L sheets and plates offer many advantages, including excellent corrosion resistance, especially in harsh environments such as chemical and coastal environments where 304L’s low carbon content increases and reduces its weldability risk of carbide precipitation, making it ideal for welding applications. It is very durable, stain resistant and requires little maintenance. 304L also has excellent strength and toughness at high and low temperatures. Its versatility makes it suitable for a wide range of industries, including food processing, pharmaceutical manufacturing and manufacturing.
Applications needing superior corrosion resistance and weldability frequently use stainless steel 304L sheets and plates. They are perfect for pipelines, storage tanks, and processing equipment in the chemical and pharmaceutical industries. They provide hygienic surfaces for manufacturing and packaging in the food and beverage industry. Additionally, 304L is frequently found in sinks, kitchenware, medical equipment, and architectural structures. It works well in non-critical saltwater applications in marine environments. Because of its low carbon content, it is particularly well-suited for welded structures where intergranular corrosion must be prevented, such as heat exchangers, pressure vessels, and piping systems.
