Kunj Sheets and Plates, a respectable manufacturer and supplier of **Stainless Steel 310S Angles** with headquarters in Delhi, India, is well-known for offering high-quality stainless steel products to a range of industries. Our stainless steel 310S angles have exceptional resistance to oxidation, corrosion, and high temperatures because they are made from a premium-grade alloy. Because these angles are ideal for offering structural support in heat-intensive applications, they are commonly used in furnaces, heat exchangers, and chemical processing settings. With careful manufacturing, strict quality control, and a customer-first mentality, Kunj Sheets and Plates ensures reliable performance, timely delivery, and competitive pricing in both domestic and international markets.
A low carbon version of stainless steel 310, 310S is renowned for its exceptional corrosion resistance and high-temperature strength. Its typical chemical composition consists of 25% chromium and 20% nickel, with a low carbon content (maximum 0.08%) to enhance weldability and decrease carbide precipitation. It has exceptional mechanical properties, such as a tensile strength of roughly 515 MPa, yield strength of 205 MPa, and elongation of 40%. 310S maintains its structural integrity at temperature.
Standard : ASTM / ASME A276 / SA276
Angle Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm etc.
Flat Size : 2mm ~ 100mm etc.
Thickness : 50 mm to 6000 mm Long
Length : 1 To 6 Meters, Custom Cut Length
Finish : Hot rolled (HR), Cold rolled (CR), Galvanized etc
| Element | SS 310S |
| C | 0.08 max |
| Mn | 2.0 max |
| Si | 1.00 max |
| P | 0.045 max |
| S | 0.030 max |
| Cr | 24 – 26 |
| Ni | 19 – 21 |
| Mo | 0.75 max |
| Fe | 53.095 min |
| Element | SS 310S |
| Density | 7.9 g/cm3 |
| Melting Point | 1402 °C (2555 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 40 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
High-quality sheets and plates made from premium materials like mild steel, galvanised steel, and stainless steel are available from Kunj Sheets and Plates. Our goods, which contain compositions of carbon, manganese, silicon, chromium, and nickel (where applicable), are designed to satisfy a variety of industrial needs. These plates and sheets have outstanding mechanical qualities, including remarkable elongation, high tensile strength, and superior yield strength. Our products are perfect for heavy engineering, fabrication, and construction applications because of their exceptional formability, weldability, and corrosion resistance, which guarantee performance, dependability, and a long service life.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Because of their superior resistance to heat and oxidation, stainless steel 310S angles are frequently utilised in corrosive and high-temperature settings. Combustion chambers, kilns, heat exchangers, and furnace parts are typical applications. They are also utilised in thermal processing equipment, power generation units, and petrochemical and chemical processing facilities. 310S angles offer robust support in structural applications for building projects that need to withstand high temperatures. Because of their dependability and low maintenance requirements, they can be used in food processing machinery, refinery equipment, and marine environments. They provide dependable performance in harsh industrial and environmental conditions.
