Offering premium structural stainless steel solutions for a range of industrial applications, Kunj Sheets and Plates is a well-known manufacturer and supplier of stainless steel 316L angles in Chennai, India. Offering corrosion-resistant and long-lasting 316L stainless steel angles to industries like construction, marine, chemical, and food processing, Kunj Sheets and Plates has a solid reputation for precise manufacturing, prompt delivery, and reliable quality. Their products are made to fit particular project specifications and come in a variety of sizes and finishes. The business is a reputable supplier of dependable stainless steel components, supported by cutting-edge infrastructure and knowledgeable engineering.
About 16–18% chromium, 10–14% nickel, and 2–3% molybdenum make up stainless steel 316L Angle. Its lower carbon content improves weldability and reduces carbide precipitation. Excellent corrosion resistance is provided by this composition, particularly in acidic and chloride environments. In terms of mechanics, it offers an elongation of about 40%, a yield strength of 170 MPa, and a tensile strength of 485 MPa. Even at cryogenic temperatures, its austenitic structure guarantees excellent toughness and ductility. Additionally, under a variety of mechanical and environmental stresses, stainless steel 316L angles retain exceptional formability and structural integrity.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 316L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 | 68.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316L | 1.4404 / 1.4435 | S31603 | SUS 316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 316L angle offers many advantages, including exceptional corrosion resistance, especially in chloride zones, making it ideal for marine and chemical applications Its low carbon content enhances its weldability and reduces risk of carbide precipitation. This material is very durable and maintains strength and performance at high temperatures. Stainless steel 316L is also non-magnetic and offers excellent formability, ensuring versatility in construction and construction applications. It is easy to maintain, offers long-term reliability and low maintenance costs, making it desirable for many businesses.
| THICKNESS | ||||||
|---|---|---|---|---|---|---|
| Size(mm) | 3 mm | 4 mm | 5 mm | 6 mm | 8 mm | 10 mm |
| 25×25 | 1.13 | 1.47 | 1.80 | 2.11 | 2.69 | — |
| 30×30 | 1.37 | 1.79 | 2.20 | 2.59 | 3.33 | — |
| 32×32 | 1.46 | 1.92 | 2.20 | 2.59 | 3.33 | — |
| 35×35 | 1.61 | 2.11 | 2.60 | 3.07 | 3.97 | — |
| 38×38 | 1.75 | 2.30 | 2.84 | 3.36 | 4.35 | — |
| 40×40 | 1.85 | 2.43 | 3.00 | 3.55 | 4.61 | — |
| 45×45 | — | 2.75 | 3.40 | 4.03 | 5.25 | — |
| 50×50 | — | — | 3.80 | 4.51 | 5.89 | 7.20 |
| 60×60 | — | — | 4.60 | 5.47 | 7.17 | 8.80 |
| 63×63 | — | — | 4.84 | 5.76 | 7.55 | 9.28 |
| 65×65 | — | — | 5.00 | 5.95 | 7.81 | 9.60 |
| 70×70 | — | — | — | 6.43 | 8.45 | 10.40 |
| 75×75 | — | — | — | 6.91 | 9.09 | 11.20 |
| 80×80 | — | — | — | 7.39 | 9.73 | 12.00 |
| 90×90 | — | — | — | 8.35 | 11.01 | 13.60 |
| 100×100 | — | — | — | 9.31 | 12.29 | 15.20 |
Angles made of stainless steel 316L are frequently utilised in structural and support applications in a variety of industries that demand exceptional durability and corrosion resistance. They are perfect for seawater-exposed frames, brackets, and reinforcements in the maritime industry. 316L angles are utilised for structural supports in corrosive environments in the petrochemical and chemical processing industries. Because of their hygienic qualities, they are also used in cleanroom construction, pharmaceutical companies, and food processing facilities. These angles are used in architecture and construction as frameworks and structural components that are subjected to inclement weather. They offer both visual appeal and durable performance under trying circumstances.
