Stainless Steel 316L Foils** typically consist of 16–18% chromium, 10–14% nickel, and 2–3% molybdenum with a maximum carbon content of 0.03%. The low carbon ensures excellent weldability and resistance to intergranular corrosion. These foils deliver a tensile strength of around 485 MPa and a yield strength of approximately 170 MPa, offering high ductility and toughness even in cryogenic conditions. SS 316L foils also exhibit excellent formability, making them ideal for deep drawing and high-precision fabrication, while maintaining outstanding corrosion resistance in both acidic and saline environments.
Stainless Steel 321 Foils consist of 17–19% chromium, 9–12% nickel, and titanium content that is at least five times the carbon content. This titanium stabilization helps prevent carbide precipitation during welding, which in turn maintains corrosion resistance. SS 321 foils boast a tensile strength of around 515 MPa and a yield strength of 205 MPa, along with excellent formability and high-temperature strength. These foils maintain their mechanical properties even at service temperatures up to 870°C, providing durability and resistance to stress corrosion cracking, scaling, and oxidation in high-heat environments.
| Item | Stainless Steel 316l foil(Hot rolled, cold rolled) | |
| Thickness | 0.025 to 3 mm and as per Customer Requirement | |
| Width | 3 mm to 2000 mm and as per Customer Requirement | |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc | |
| Surface | the surface and finish of stainless steel 316l foil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe | |
| SS 316L | 0.035 max | 2.00 max | 1.00 max | 0.045 max | 1.0 max | 16.00-18.00 | 2.0 -3.0 | 10.0 – 14.0 | 68.89 min |
| Properties | Metric | Imperial | |
| Tensile strength (transverse at room temperature) | 685 MPa | 99400 psi | |
| Tensile strength (longitudinal at room temperature) | 696 MPa | 101000 psi | |
| Yield strength (transverse at room temperature) | 292 MPa | 42400 psi | |
| Yield strength (longitudinal at room temperature) | 301 MPa | 43700 psi | |
| Compressive yield strength | 365 MPa | 52900 psi | |
| Elastic modulus | 197 GPa | 28573 ksi | |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 | |
| Elongation at break (longitudinal at room temperature) | 56% | 56% | |
| Elongation at break (transverse at room temperature) | 62.50% | 62.50% | |
| Hardness, Rockwell B (transverse at room temperature) | 85 | 85 | |
| Hardness, Rockwell B (longitudinal at room temperature) | 85 | 85 |
Stainless Steel 316L Foils offer numerous advantages, including exceptional corrosion resistance, especially in harsh environments such as marine and chemical applications. They are highly resistant to pitting, crevice corrosion, and stress corrosion cracking, making them ideal for use in aggressive conditions. The low carbon content enhances weldability, reducing carbide precipitation during welding. 316L foils exhibit excellent strength, durability, and formability, making them suitable for precision applications. Additionally, they are biocompatible, making them ideal for medical and food processing industries, ensuring long-term performance and reliability.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 316l | 1.4404 | S31603 | SUS 316l | Z7CND17‐11‐02 | 316S11/316S13 | – | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Stainless Steel 321 Foils are perfect for aerospace components, exhaust systems, thermal insulation, and heat exchanger linings due to their stability at elevated temperatures. In the chemical processing sector, they are utilized for furnace linings, reactor linings, and equipment that faces acidic and oxidizing conditions. The automotive industry makes use of SS 321 foils in flexible connectors, gaskets, and catalytic converter sheathing. These foils are also crucial in power plants, pharmaceutical manufacturing, and oil & gas applications, where corrosion resistance, strength, and heat tolerance are vital for long-lasting performance.
