Located in Chennai, India, Kunj Sheets and Plates is a well-known producer and supplier of 316Ti stainless steel foils, providing premium goods designed for demanding industrial uses. 316Ti foils are well-known for their exceptional heat stability and resistance to corrosion, making them perfect for settings with high temperatures and harsh chemicals. Kunj Sheets and Plates produces foils that satisfy international standards by combining sophisticated manufacturing processes with strict quality control. Serving sectors like food production, marine, pharmaceuticals, and chemical processing, Kunj is dedicated to offering long-lasting, precisely fabricated stainless steel solutions that meet the needs of every customer.
About 16–18% chromium, 10–14% nickel, 2–3% molybdenum, and titanium added at roughly five times the carbon content make up stainless steel 316Ti, a titanium-stabilized version of 316. After welding, titanium increases resistance to intergranular corrosion and improves performance at high temperatures. The alloy has a yield strength of 205 MPa, a tensile strength of about 515 MPa, and an elongation of about 40%. Excellent toughness, ductility, and formability are provided by its austenitic structure. 316Ti is appropriate for applications needing thermal and chemical durability because it retains its mechanical strength and resistance to corrosion in high-heat settings.
| Item | Stainless Steel 316ti foil(Hot rolled, cold rolled) | |
| Thickness | 0.025 to 3 mm and as per Customer Requirement | |
| Width | 3 mm to 2000 mm and as per Customer Requirement | |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc | |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc | |
| Surface | the surface and finish of stainless steel 316ti foil: 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc | |
| Package | Shrink-wrapped ,Carton boxes,Wooden pallets,Wooden boxes ,Wooden crates Etc. required. |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | ||
| 316TI | Min | – | – | – | – | – | 16.0 | 2.00 | 10.0 | – | |
| max | 0.08 | 2 | 0.75 | 0.045 | 0.03 | 18.0 | 3.00 | 14.0 | 0.1 |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | ||
| Rockwell B (HR B) max | Brinell (HB) max | |||||
| 316TI | 515 | 205 | 35% | 75 | 205 | |
Stainless Steel 316Ti foils offer exceptional resistance to corrosion, especially in aggressive environments like chemical processing, marine, and high-temperature applications. The addition of titanium enhances its strength, making it ideal for use in structures exposed to heat and harsh chemicals. These foils maintain excellent weldability, formability, and durability, ensuring reliable performance. Additionally, Stainless Steel 316Ti provides superior pitting and crevice corrosion resistance compared to other stainless steels, making it a top choice for industries demanding high-performance materials with long-lasting reliability in extreme conditions.
| STANDARD | WERKSTOFF NR. | UNS | JIS | AFNOR | BS | GOST | EN | |
| SS 316ti | 1.4571 | S31635 | SUS 316ti | Z6CNDT17‐12 | 320S31 | 08Ch17N13M2T | X6CrNiMoTi17-12-2 |
Applications where corrosion resistance and high-temperature stability are essential are best suited for stainless steel 316Ti foils. They are used to line tanks, heat exchangers, and equipment exposed to aggressive substances in chemical and petrochemical plants. 316Ti foils are used in the food processing and pharmaceutical industries to maintain hygienic conditions and prevent corrosion in high-moisture, acidic environments. They are utilised by the marine industry in parts that are exposed to salty environments and seawater. Because of their resistance to oxidation and scaling, these foils are also utilised in insulation wrap, exhaust systems, and furnace parts. They are also perfect for custom-fabricated thermal barriers because of their formability.
