Kunj Sheets and Plates, Delhi, India, is a well-established brand in the stainless steel sector, with a diverse product line of high-performance products for industrial and structural applications. Of their high-end products, Stainless Steel 317 Channels are notable for their exceptional corrosion resistance and mechanical strength in aggressive conditions. Created to international specifications, these channels are ideal for application in chemical, petrochemical, and marine environments. Kunj integrates sophisticated manufacturing technology, strict quality control, and customer-centric methodology to provide stainless steel solutions that translate into durability, accuracy, and sustained performance under harsh operating environments.
Stainless Steel 317 Channel is an austenitic stainless steel of high alloy with improved corrosion resistance owing to higher molybdenum content. Its chemical composition is Chromium (18–20%), Nickel (11–15%), Molybdenum (3–4%), Carbon (≤0.08%), Manganese (≤2%), Silicon (≤1%), and balance Iron. This alloy provides good resistance to pitting, crevice corrosion, and chemical attack under acidic and chloride-containing environments. It contains a tensile strength of approximately 515 MPa, yield strength of 205 MPa, and elongation of 40%. SS 317 also provides a good weldability, formability, and high-temperature strength, thus finding its application in heavy-duty and corrosion-susceptible structural use.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 317L | 0.035 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 18.00 – 20.00 | 3.00 – 4.00 | 11.00 – 15.00 | 57.89 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Stainless Steel 317 channels offer numerous advantages, particularly in environments where corrosion resistance is critical. The high levels of molybdenum and chromium enhance its resistance to pitting, crevice corrosion, and oxidation, especially in acidic and chloride-rich conditions. This makes it ideal for chemical processing, pharmaceutical, and food production industries. The material’s excellent weldability and formability allow for easy fabrication into complex structures. Additionally, Stainless Steel 317 channels provide superior strength, durability, and performance at both high and low temperatures, ensuring reliable, long-lasting use in demanding applications with minimal maintenance.
Yes, we offer custom sizes for Stainless Steel 317 Channel to meet specific project needs. Our team at Kunj Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@kunjsheetsandplates.co.in.
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 317L | 1.4438 | S31703 | SUS 317L | X2CrNiMo18-15-4 |
Stainless Steel 317 Channels are employed in strongly corrosive environments where normal stainless steels can fail. Typical uses are in chemical processing equipment, pulp and paper production, marine applications, desalination facilities, and acid and chemical storage tanks. Their increased resistance to sulfuric acid and chloride solutions makes them very suitable for heat exchangers, evaporators, and pollution control systems. SS 317 Channels find application in food and pharmaceutical processing machinery when superior cleanliness and corrosion resistance are requirements. With very good structural integrity, resistance to chemical degradation, and thermal stability, the channels are a reliable option for load-bearing applications and fabrication in abusive industrial environments.
