Located in Chennai, India, Kunj Sheets and Plates is a top producer and supplier of high-performance 317L stainless steel foils. The business serves a variety of industries, including pulp and paper, chemical processing, marine, and pharmaceuticals, and is renowned for producing high-quality, corrosion-resistant products. Punj Sheets and Plates guarantees precisely engineered foils that satisfy international standards through sophisticated manufacturing facilities, strict quality control, and an emphasis on customer satisfaction. Their 317L stainless steel foils are a great option for demanding applications needing strength, durability, and dependable performance in corrosive environments because of their exceptional resistance to harsh chemicals and high moisture environments.
Stainless Steel 317L is an austenitic, low-carbon steel that contains molybdenum. It has about 18–20% chromium, 11–15% nickel, and 3–4% molybdenum. While the high molybdenum content increases resistance to pitting and crevice corrosion, the low carbon content improves weldability and resistance to intergranular corrosion. It has an approximate elongation of 35–40%, a yield strength of 205 MPa, and a tensile strength of 515 MPa. Excellent ductility, formability, and toughness are provided by the austenitic structure. Because of these characteristics, 317L foils are ideal for use in environments that are acidic, corrosive, and chloride-rich, especially when extended chemical exposure is anticipated.
| SPECIFICATION: | ASTM A240 / SA240 |
| STANDARD | JIS, AISI, ASTM, DIN, GB, EN, ETC |
| SURFACE | 2B, CR, HR, 2D, NO.4, NO.8, MIRROR, BA, NO.1, CHEQUERED, HAIRLINE, BRUSH, ETCHING, ETC. |
| WIDTH | 1000MM, 1219MM, 1250 MM, 1500MM, 2000MM AND Even as per Customers Requirements |
| LENGTH | 2000MM, 2500MM, 3000 MM, 5000MM, 6000MM AND Even as per Customers Requirements |
| THICKNESS | 0.05MM TO 150 MM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 317L | 0.035 max | 2 max | 1 max | 0.040 max | 0.03 max | 18 – 20 | 3 – 4 | 11 – 15 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Stainless Steel 317L foils offer exceptional corrosion resistance, particularly in acidic environments, making them ideal for chemical processing, marine, and pharmaceutical industries. Their low carbon content enhances weldability and reduces the risk of carbide precipitation, ensuring improved performance in high-temperature applications. These foils have excellent formability and are highly resistant to pitting, crevice corrosion, and stress corrosion cracking. With superior strength and durability, Stainless Steel 317L foils are widely used in industries requiring materials that maintain integrity under harsh conditions. Their versatility makes them suitable for various applications, from heat exchangers to reactors.
| GRADE 317L | ||||
|---|---|---|---|---|
| ASTM | DIN | UNS | JIS | GB |
| 317L | 1.4438 | S31703 | SUS317L | X2CrNiMo19-14-4 |
Industries requiring exceptional mechanical strength and corrosion resistance frequently use stainless steel 317L foils. They are perfect for lining heat exchangers, tanks, and reactors exposed to harsh chemicals and acids in petrochemical and chemical processing. They serve as anti-corrosion barriers, insulation, and protective wraps in maritime settings. 317L foils are used in the pulp and paper industries for digesters and bleach plants. They are also appropriate for use in power generation, pharmaceuticals, and food processing. 317L foils are great for custom-fabricated parts that operate in harsh or corrosive environments because of their flexibility, weldability, and resistance to corrosion.
