Based in Chennai, India, Kunj Sheets and Plates is a top producer and supplier of high-quality stainless steel 321 sheets and plates. The company, which serves a variety of industries including power generation, automotive, chemical, and aerospace, is renowned for providing premium stainless steel products with accuracy and dependability. International performance and durability standards are met by Kunj Sheets and Plates’ products thanks to their sophisticated manufacturing capabilities and stringent quality control. Because of their exceptional resistance to intergranular corrosion and high-temperature oxidation, their Stainless Steel 321 products are in high demand and perfect for demanding industrial applications.
About 17–19% chromium, 9–12% nickel, and trace amounts of titanium (≥5 times the carbon content) are present in Stainless Steel 321, an austenitic stainless steel stabilised by titanium. After being exposed to high temperatures, this composition improves resistance to intergranular corrosion. The alloy has an approximate elongation of 40%, a yield strength of 205 MPa, and a tensile strength of 515 MPa. At higher temperatures, it maintains its oxidation resistance and mechanical strength. In addition to being non-magnetic when annealed, stainless steel 321 has outstanding formability and weldability, particularly in hot conditions.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 321 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 5(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 321 | 1.4541 | S32100 | SUS 321 | X6CrNiTi18-10 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 321 sheets and plates have several key advantages, making them ideal for high temperature applications. They exhibit excellent resistance to oxidation, corrosion and carburization, especially at temperatures up to 900°C (1650°F). The titanium content improves the stability of the alloy and prevents carbide precipitation during welding, increasing its durability and strength. Stainless steel 321 is also highly resistant to stress corrosion cracking and provides excellent formability and weldability. These characteristics make it ideal for industries such as aerospace, chemical processing and power generation, where reliability and long-term performance are critical.
Applications involving persistently high temperatures and corrosive conditions frequently use stainless steel 321 sheets and plates. Because of their exceptional thermal stability, they are frequently utilised in aerospace engineering for engine parts, exhaust systems, and thermal shields. 321 is perfect for furnace components, reactor vessels, and heat exchangers in the chemical and petrochemical industries. Additionally, refinery equipment, boiler tubes, and expansion joints use it. Because of its resistance to oxidation and intergranular corrosion, it can be used in pressure vessels, high-temperature gaskets, and automotive manifolds, providing extended service life and requiring less maintenance under harsh circumstances.
