Kunj Sheets and Plates is a leading producer and supplier of top-class Stainless Steel 347H Sheets and Plates in Delhi, India. It is renowned for its quality, accuracy, and durability. Kunj supplies high-performance SS 347H products to both domestic and international customers. The company uses the latest manufacturing technology coupled with rigorous quality checks to ensure that every sheet and plate produced surpasses global standards. Stainless Steel 347H, a carbon-rich form of 347, is best suited for use at high temperatures. Timely delivery, competitive prices, and complete customer satisfaction have brought Kunj a trusted reputation in numerous industrial segments.
Stainless Steel 347H Sheets and Plates consist primarily of chromium (17–20%), nickel (9–13%), and carbon (0.04–0.10%) along with columbium/tantalum to improve stabilization. This alloy possesses superior oxidation resistance and creep strength at high temperatures. It provides tensile strength of approximately 515 MPa, yield strength of 205 MPa, and elongation of about 35%. Its high carbon content enhances high-temperature strength due to which it finds applications in pressure vessels as well as heat exchangers. The superior weldability and corrosion resistance provided by this alloy make it a preferable component for numerous demanding applications.
| Specifications | : | ASTM A240 / ASME SA240 |
| Thickness | : | 4mm-100mm |
| Width | : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Surface | : | 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Form | : | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc. |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti |
| SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | EN |
| SS 347H | 1.4961 | S34709 | SUS 347H | X12CrNiTi18-9 |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 347H sheets and plates offer many benefits, making them ideal for high-temperature environments. High carbon content increases strength, while the presence of columbium improves intergranular corrosion resistance especially in welded structures Its excellent oxidation and corrosion resistance makes it suitable for petrochemical power generation and aerospace applications. Furthermore, 347H exhibits excellent weldability, making it easy to manufacture. The material also maintains structural integrity at high temperatures, ensuring durability and reliability in demanding applications. These features make the 347H the ideal choice for critical, high-performance applications.
Stainless Steel 347H Plates and Sheets find extensive application in high-temperature and corrosive environment resistant industries. Typical applications include furnace components, superheaters, boilers, and heat exchangers in chemical, petrochemical, oil & gas, and power generation industries. Because of its outstanding creep strength and mechanical properties, 347H is particularly suitable for pressure vessels and piping systems in high-temperature conditions. It also finds application in aerospace, pharmaceutical, and food processing machinery where durability, oxidation resistance, and hygiene are paramount. Stability under extreme conditions guarantees long service life and consistent performance in varied industrial processes.
