Kunj Sheets and Plates is a trustworthy producer and supplier of Stainless Steel 415 sheets and plates in Delhi, India, providing high-strength materials for use in applications needing superior hardenability and modest corrosion resistance. Our SS 415 sheets and plates are designed to provide better mechanical performance, particularly under heat-treated conditions. With accuracy in manufacturing and compliance with international standards of quality, we provide these products to automotive, aerospace, oil & gas, and engineering industries with long-term durability, strength, and cost-effective solutions for heavy-duty structural and mechanical operations.
Stainless Steel 415 is a martensitic stainless steel that is high in chromium (12–14%) and contains high carbon content (0.05–0.15%) which can be further increased with molybdenum and other elements for added strength. It possesses great hardenability and wear resistance when heat treated, and moderate corrosion resistance. Mechanical properties are tensile strength up to 760 MPa, yield strength of approximately 450 MPa, and good toughness in tempered conditions. Its magnetic characteristics and the fact that it retains strength at elevated temperatures make it ideal for challenging load-bearing applications.
| Specifications : | ASTM A240 / ASME SA240 |
| Dimensions : | ASTM, ASME and API |
| Standard : | JIS, AISI, ASTM, GB, DIN, EN, etc. |
| Surface : | 2B, 2D, BA, NO.4, NO.8, 8K, Mirror,Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching |
| Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm,etc. |
| Finish : | Black,Bright Polished,Rough Turned,No.4 Finish,Matt Finish,BA Finish |
| Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc. |
| Grade | C | Mn | P | S | Si | Ch | Ni | Mo |
| SS 415 | 0.05 max | 0.50-1.00 | 0.030 max | 0.030 max | 0.60 max | 11.5-14.0 | 3.5-5.5 | 0.50-1.00 |
| Tensile Strength R₃ N/mm² | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 | 700-800 |
| 0.2% Offset Yield Strength Rᵖ ≥N/mm² | 520 | 520 | 520 | 520 | 520 | 520 | 520 |
| Elongation in 2 inches, % | 15 min | 15 min | 15 min | 15 min | 15 min | 15 min | 15 min |
| Grade | WERKSTOFF NR. | UNS | AISI |
| SS 415 | 1.4313 | S41500 | F6NM |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Grade | Density lbm/in3 | Melting Range(°F) | Thermal Conductivity(BTU-in/hr- ft. °F) | Electrical Resistivity(in x 10-6) | Modulus of Elasticity (psi x 106 | Coefficient of Thermal Expansion (in/in)/°F x 10-6 | Specific Heat(BTU/lb/°F) |
|---|---|---|---|---|---|---|---|
| 415 | -at 68°F: 0.280 | 2700 to 2790 | 187 at 212°F | 23.7 at 68°F | 29 | 6.0 at 32 – 212°F | 0.11 at 68°F to 212°F |
| – | – | – | – | – | 7.5 at 68 – 1200°F | – |
| Metric | density (g/cm³) | x | T | x | W | x | L | = | weight |
|---|---|---|---|---|---|---|---|---|---|
| Example | 4.50g/cm³ | x | 6mm | x | 2m | x | 1m | = | 54.00 kg |
| Imperial | density (lbs/in³) | x | T | x | W | x | L | = | weight |
| Example | 0.163 lbs/in³ | x | 4in | x | 48in | x | 144in | = | 4506.6 lbs |
Stainless Steel 415 Sheet and Plates has several advantages, including superior strength, durability, and corrosion resistance, especially after heat treatment. Its martensitic structure provides excellent corrosion resistance, making it suitable for harsh environments. The durability of the product further enhances its durability and performance in high-pressure applications. In addition, it offers better machinability and lower cracking properties compared to other high-strength materials. Stainless steel 415 is widely used in the manufacture of products such as valves, pumps and equipment, providing reliable performance in both industrial and industrial applications.
Stainless Steel 415 plates and sheets have extensive application where high mechanical strength, wear resistance, and moderate corrosion protection are required. Typical applications include turbine parts, shafts, gears, bolts, valves, industrial blades, and pump components. They find application in high-temperature equipment, petrochemical process plant equipment, and automotive powertrain systems. Owing to their good heat treatment response and ability to support stress structure, SS 415 sheets and plates are perfect for applications involving friction, heavy loads, and exposure to mild corrosive chemicals, providing long-term reliability and performance.
