Located in Chennai, India, Kunj Sheets and Plates is a reputable manufacturer and supplier of premium stainless steel 422 sheets and plates for uses requiring extraordinary strength and heat resistance. Kunj uses cutting-edge manufacturing processes and exacting quality standards to create 422-grade stainless steel products with a dedication to excellence. These sheets and plates are a popular option in industrial, power generation, and aerospace applications because they are perfect for high-stress, high-temperature settings. Kunj has established itself as a reliable partner for stainless steel needs in both the Indian and international markets thanks to its commitment to accuracy, prompt delivery, and customer satisfaction.
With additions of molybdenum, tungsten, and vanadium to improve strength and heat resistance, Stainless Steel 422 is a hardenable martensitic stainless steel alloy that contains roughly 11.0–13.0% chromium and 0.20–0.25% carbon. With a yield strength of about 415 MPa and a tensile strength range of 655–965 MPa, this alloy can be heat treated to achieve high strength and hardness. At temperatures as high as 1200°F (649°C), it provides outstanding resistance to creep and oxidation while retaining good toughness. In harsh operating conditions, stainless steel 422 offers dependable mechanical performance and is magnetic.
| Specifications : | ASTM A240 / ASME SA 240 |
| Dimensions : | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, IS & Custom Chemistry |
| Production Route : | Hot Rolled, Cold Rolled |
| Size : | Width from 100mm to 3000mm ; Length from 500mm to 12000mm |
| Thickness : | 0.1mm to 400mm |
| Delivery Condition : | As Rolled, Annealed, Quenched and Tempered, Normalized |
| Surface Finish : | Plain, Brushed, Cladded |
| Grade | C | P | Si | Ni | V | Fe | Mn | S | Cr | Mo | W | Cu |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| SS 422 | 0.20-0.25 | 0.040 max | 0.20-0.60 | 0.50-1.0 | 0.17-0.30 | Bal | 1.0 | 0.030 max | 11.0-13.5 | 0.75-1.25 | 0.75-1.25 | 0.50 |
| Material | Condition | 0.2 % Yield Strength (ksi) | Ultimate Tensile Strength (ksi) | % Elongation in 2″ | % Reduction of Area | Hardness HB |
|---|---|---|---|---|---|---|
| SS 422 | Hardened & Tempered (AMS 5655) | 140 | 115 | 13 | 25 | 293-341 |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| SS 422 | 1.4935 | S42200 |
| Density (lb / cu. in.) | 0.287 |
| Specific Gravity | 7.94 |
| Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | 0.12 |
| Electrical Resistivity (microhm-cm (at 68 Deg F)) | 432 |
| Melting Point (Deg F) | 2590 |
| Modulus of Elasticity Tension | 28 |
| METAL GAUGE | (APPROXIMATE INCHES) | NOMINAL DECIMAL (+/- INCHES) |
|---|---|---|
| 7 | 0.1793 | 0.0080 |
| 8 | 0.1644 | 0.0080 |
| 9 | 0.1495 | 0.0080 |
| 10 | 0.1345 | 0.0070 |
| 11 | 0.1196 | 0.0050 |
| 12 | 0.1046 | 0.0050 |
| 13 | 0.0897 | 0.0050 |
| 14 | 0.0747 | 0.0040 |
| 15 | 0.0673 | 0.0040 |
| 16 | 0.0598 | 0.0030 |
| 17 | 0.0538 | 0.0030 |
| 18 | 0.0478 | 0.0030 |
| 19 | 0.0418 | 0.0030 |
| 20 | 0.0359 | 0.0030 |
| 21 | 0.0329 | 0.0025 |
| 22 | 0.0299 | 0.0020 |
| 23 | 0.0269 | 0.0020 |
| 24 | 0.0239 | 0.0020 |
| 25 | 0.0209 | 0.0015 |
| 26 | 0.0179 | 0.0015 |
| 28 | 0.0149 | 0.0010 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 422 sheets and plates offer many advantages, including excellent increased strength and oxidation resistance, making them ideal for applications in harsh environments such as turbine heat exchangers They provide excellent corrosion resistance , ensure durability under extreme conditions Their high tensile strength and strength enhance the reliability of the structures, while mechanical practicality and ease of manufacture. These sheets and plates remain stable and durable under stress, providing longevity. In addition, the cost-effectiveness and compatibility of heat treatments provides assets tailored to specific industrial applications, resulting in versatile and reliable products.
Because of their superior mechanical qualities and resistance to heat, stainless steel 422 sheets and plates are frequently used in high-temperature and high-stress applications. They are used in exhaust systems, jet engine parts, and turbine components in the aerospace sector. They are used in combustion chamber components, pressure vessels, and steam turbines in the power generation industry. They are appropriate for heat-treating fixtures, bolts, fasteners, and furnace components in industrial manufacturing. 422 stainless steel is also utilised in thermal processing and defence equipment because it provides long-term performance and durability in applications where structural integrity, strength, and resistance to oxidation are crucial.
