Kunj Sheets and Plates is a trusted manufacturer and supplier of Stainless Steel 446 Sheets and Plates, headquartered in Chennai, India. Our high-performance SS 446 products are crafted to withstand extreme temperatures and highly corrosive environments. Stainless Steel 446 is a ferritic, heat-resistant alloy containing high chromium content, offering excellent oxidation and sulfidation resistance at elevated temperatures. It is ideal for furnace components, heat exchangers, and other thermal processing applications. At Kunj, we ensure dimensional precision, top-grade material quality, and reliable supply to cater to clients in power generation, petrochemical, and industrial manufacturing sectors across India and internationally.
Stainless Steel 446 Sheets and Plates are primarily composed of 23–27% chromium, with low carbon content and minor additions of silicon and molybdenum. This ferritic stainless steel offers outstanding resistance to oxidation, scaling, and sulfidation at temperatures up to 1100°C. It has a tensile strength of approximately 485 MPa and yield strength around 275 MPa, with good creep strength at elevated temperatures. Though less formable than austenitic grades, it has excellent corrosion resistance in high-temperature environments and moderate mechanical properties, making it ideal for static and thermal applications in aggressive atmospheres.
| 446 Sheets & Plates Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 446 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 446 Sheets & Plates Size Range | Cold rolled ASME SA240 Grade 446 Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASME SA240 Grade 446 Stainless Steel Sheet 3.0–10.0 mm |
| 446 SS Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| SS 446 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| SS 446 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Stainless Steel 446 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 446 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SA240 446 SS Strips EN 10088 SA -240-446 Strips |
| Finish of SS 446 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Stainless Steel 446 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| SS 446 | 0.2 max | 1.5 max | 0.75 max | 0.04 max | 0.030 max | 23 – 30 | – | 0.50 max | 0.10 – 0.25 | Balance |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.5 g/cm3 | 1510 °C (2750 °F) | Psi – 75,000 , MPa – 485 | Psi – 40,000 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS | BS | EN | JIS |
| SS 446 | 1.4762 | S44600 | 446S21 | X12Cr13 | SUS 446 |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 446 sheets and plates have many advantages, making them ideal for high temperature applications. They provide exceptional resistance to oxidation, corrosion and scaling, even in extreme environments. The high chromium content increases the ability to withstand high temperatures and increases durability. These materials also provide excellent thermal conductivity and strength while maintaining structural integrity in extreme conditions. In addition, Stainless Steel 446 is resistant to chloride stress corrosion and cracking, making it suitable for use in industrial furnaces, heat exchangers, and other complex applications where reliability is critical.
Stainless Steel 446 Sheets and Plates are primarily composed of 23–27% chromium, with low carbon content and minor additions of silicon and molybdenum. This ferritic stainless steel offers outstanding resistance to oxidation, scaling, and sulfidation at temperatures up to 1100°C. It has a tensile strength of approximately 485 MPa and yield strength around 275 MPa, with good creep strength at elevated temperatures. Though less formable than austenitic grades, it has excellent corrosion resistance in high-temperature environments and moderate mechanical properties, making it ideal for static and thermal applications in aggressive atmospheres.
