Kunj Sheets and Plates is a well-known manufacturer and supplier of Stainless Steel 465 plates and sheets in Delhi, India, and provides high-performance materials for aerospace, defense, and other critical usage. Our SS 465 plates and sheets have been acclaimed for their ultra-high strength, high toughness, and good corrosion resistance even in harsh service conditions. Produced to precise specifications and heat-treated for high performance, these sheets and plates are perfect for high-stress structural parts. We serve industries with high-tech material needs of reliability, long life, and precision-engineered strength-to-weight ratios.
Stainless Steel 465 is a precipitation-hardened martensitic stainless steel containing about 11–12% Chromium, 10.5–11.5% Nickel, 1.5% Titanium, and minor additions of Molybdenum and Iron. It can be heat-treated to extremely high strength levels with the retention of excellent toughness and stress corrosion cracking resistance. The alloy has tensile strengths over 1,550 MPa and yield strengths over 1,380 MPa following aging. Although very strong, SS 465 provides moderate corrosion resistance in atmospheric and industrial atmospheres and has good formability in the annealed state.
| Standard Specification : | ASTM A240 / ASME SA240 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Fe 74.35% | Cr 11.75% | Ni 11.0% | Ti 1.65% | Mo 2.05% | |||||
| Mn <=0.25% | Si <=0.25% | C <=0.020% | P <=0.015% | N <=0.010% | |||||
| S 0.010% | |||||||||
| Property | Minimum | Maximum | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Yield Strength Range (Rp0.2 Offset) (ksi) | 170 | 270 | |||||||
| Tensile Strength Range (Rm) (ksi) | 190 | 280 | |||||||
| Elongation (AL=5 x Ø) | 2.3% | 14.0% | |||||||
| Brinell Hardness (H) | 271 | 560 | |||||||
| Modulus of Elasticity (ksi) (E): 32000 | |||||||||
| Machineability General Index: Unknown | |||||||||
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| SS 465 | 1.4614 | S46500 |
| Density | Electrical conductivity (% IACS) | Thermal conductivity (BTU-in/hr-ft²-°F) | Specific heat capacity | Thermal expansion (1/°F) | Melting Point (°F) |
| 0.2822 | 2.05 | 97 | 0.107 | 0.00000572 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 465 sheets and plates offer many advantages, such as exceptional strength, corrosion resistance and corrosion resistance, making them ideal for harsh environments Their high tensile and yield strengths ensure durability and it lasts for a long time even in harsh conditions. SS 465 maintains system integrity at high temperatures, making it suitable for high temperature applications. In addition, it provides excellent durability, with resistance to abrasion and deformation. With excellent formability and weldability, it is versatile for a variety of industrial applications, including aerospace, chemical processing, and heavy-duty production SS 465 for reliability and performance.
Stainless Steel 465 plates and sheets find extensive application in areas where strength and reliability under extreme conditions are a must. Some of the common uses are in aerospace fasteners, structural parts of airframes, components of landing gears, missile components, components of turbine engines, and high-performance springs. They are employed in medical equipment, high-pressure tools, and specialized tooling. The union of high strength, fracture toughness, and corrosion resistance of SS 465 makes it suitable for weight-critical and harsh environments, especially in the aerospace and defense sectors, where material failure is unacceptable.
