Kunj Sheets and Plates is a well-known Delhi-based manufacturer and supplier of Stainless Steel 904L angles, providing high-performance products optimized for use in highly corrosive and challenging conditions. Our 904L stainless steel angles are renowned for their outstanding resistance to aggressive acids, pitting, and chloride-induced corrosion, positioning them as a favorite for structural and support applications in extreme industrial environments. Produced with utmost precision and quality-inspected to international standards, we provide these angles to industries like chemical processing, marine, pharmaceutical, and offshore industries with long-lasting durability, structural integrity, and working reliability.
Stainless Steel 904L is a low carbon non-stabilized austenitic stainless steel alloy that contains a high concentration of alloying elements such as 19–23% Chromium, 23–28% Nickel, 4–5% Molybdenum, and 1–2% Copper. Adding copper enhances its resistance to reducing acids such as sulfuric acid. Its mechanical properties consist of a minimum tensile strength of 490 MPa, yield strength of 220 MPa, and elongation of 35%. These make the 904L angles very suitable for conditions that need strength, toughness, and resistance to corrosion in harsh chemical and marine environments.
Specifications : ASTM A276, ASTM A479 / ASME SA276, ASME SA479
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness: 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Cu |
| SS 904L | 0.020 max | 2.00 max | 1.00 max | 0.040 max | 0.030 max | 19.00 – 23.00 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.95 g/cm3 | 1350 °C (2460 °F) | Psi – 71000 , MPa – 490 | Psi – 32000 , MPa – 220 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | KS | AFNOR | EN |
| >SS 904L | 1.4539 | N08904 | SUS 904L | 904S13 | STS 317J5L | Z2 NCDU 25-20 | X1NiCrMoCu25-20-5 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Kunj Sheets and Plates based in Chennai, India, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
The stainless steel 904L angle offers many advantages, including excellent corrosion resistance, especially in acidic environments, which makes it ideal for applications such as chemical processing, seawater handling and more etc. Highly resistant to pitting and crevice corrosion, ensuring durability in extreme conditions. The alloy offers excellent weldability and formability, making it versatile for a variety of structural applications. With increased strength and durability, the stainless steel 904L Angle maintains its integrity under extreme temperatures and pressures. The low carbon content reduces carbide precipitation and increases corrosion resistance in high-temperature environments.
Stainless Steel 904L angles have found extensive usage in applications involving structures where corrosion resistance as well as mechanical strength is essential. Common applications are support structures for chemical plants, marine structures, pollution control devices, offshore oil platforms, and storage tanks subject to corrosive medium. They are also utilized in heat exchangers, architectural structures, and pharmaceutical equipment. Because of their resistance to acids, chlorides, and high temperatures, 904L angles provide a corrosion-resistant solution for harsh environments where conventional stainless steels might corrode, allowing for low maintenance and long life of service.
